8. Fixing the Brackets Position with the Antiskid Blocks
D
Install the both antiskid blocks as close to the adapter brackets as possible.
Tighten screws on the antiskid blocks using a proper screwdriver to prevent display from moving.
9. Lock the Pop-out Module with the Plastic Locking Pieces
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your distributor if you have any questions.
Video Wall Mount
200x200
/300x300
AS0346T
400x200/400x400
600x400
200x200
/300x300
AS0348T
400x200/400x400
600x400/800x400
INSTALLATION MANUAL
CAUTION:
DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
70"
70kg
70kg
MAX
(154lbs)
(154lbs)
RATED
RATED
ISSUED: SEP. 2014
Advertisement
Table of Contents
Related Manuals for AllMounts AS0346T
Summary of Contents for AllMounts AS0346T
- Page 1 Tighten screws on the antiskid blocks using a proper screwdriver to prevent display from moving. 9. Lock the Pop-out Module with the Plastic Locking Pieces CAUTION: DO NOT EXCEED RATED LISTED WEIGHT. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! 200x200 /300x300 AS0346T 400x200/400x400 600x400 70" 70kg 70kg (154lbs) (154lbs) 200x200...
- Page 2 Component Checklist NOTE: Read the entire instruction manual before you start installation and assembly. IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, telephone your local distributor for a replacement. WARNING •...
- Page 3 1. For Solid Brick and Concrete Wall Mounting 2. For Video Wall Installation (Mounting space as shown below) X=Length of display Y=Height of display 60mm 60mm (2.4") (2.4") ø 10mm (ø 3/8") Mark the Drill pilot holes exact location of mounting holes 3.
- Page 4 4. Installing the Adapter Brackets 4-2. For Bump-out or Recessed Back Screens Top of the display M-C M-D/M-E M-D/M-E M-D/M-E 4-1 For Flat Back Screens Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screen. ·...
- Page 5 6. Adjustment Left Left Right Right Push the display to left or right to enable fast alignment. Left Left Handles for tilt adjustment. Screws for micro-adjustment of up and down. Right Right Knobs for micro-adjustment of in and out. Left Left Right Right...
- Page 6 7. Level the Displays wall Left Left Right Right Adjust the display to keep level in vertical and horizontal directions. 1.2mm Note: Use the plastic locking piece to measure and keep a Right Right 1.2 mm gap between displays. Left Left Note: Install/adjust the displays by the...
