- Page 1 INSTALLATION MANUAL Monitor Table Stand CAUTION: DO NOT EXCEED RATED LISTED WEIGHT. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! 27" 75x75 AS01T01 100x100 (17.6lbs) (17.6lbs) RATED RATED ISSUED: OCT. 2014...
- Page 2 Component Checklist NOTE: Read the entire instruction manual before you start installation and assembly. IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, telephone your local distributor for a replacement. WARNING •...
- Page 3 1. Separating the VESA Plate 2. Assembling the Pole to Base • Use Allen key to loosen the screws in Loosen screws on the base. The pole is screwed into the order to separate the VESA plate from the threaded hole of the base. adapter bracket assembly.
- Page 4 3. Installing the Articulated Arm Assembly adjust height loosen collar Insert the articulated arm assembly Adjust the collar to the desired into the pole untill it touches the collar. height as needed. collar adjust handle tighten tighten Note: Plastic handle can be pulled out due to a limited amount of space.
- Page 5 4. Installing the VESA Plate 5. Installing the Display Top of display Insert the VESA plate onto the mount and use the previously removed screws to secure them. Make sure the display is safely secured before finally releasing. 6. Cable Management Screw the VESA plate onto the display.
- Page 6 7. Adjustment Maintenance • Check that the bracket is secure and safe to use at regular intervals(at least every three months). • Please contact your distributor if you have any questions. Slightly loosen or tighten the screws as required due to different weights of the displays.
