8
7
5
4
2
1
Note: The displays are installed by the numerical order given.
2
1
5
4
8
7
Note: The angle of displays are adjusted by the numerical order given.
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your distributor if you have any questions.
9
6
3
3
6
9
Video Wall Stand & Cart and Accessories
300x300/400x200
AS01346FW
400x400/600x400
300x300/400x200
AS01346FF
400x400/600x400
INSTALLATION MANUAL
Optional Accessories
AS01K
Note: The accessories
are not standard equipped.
The accessories will be
selected according to
user requirement.
CAUTION:
DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
55"
MAX
50kgx3
50kgx3
(110lbsx3)
(110lbsx3)
55"
RATED
RATED
MAX
ISSUED: FEB. 2014
Advertisement
Table of Contents
Related Manuals for AllMounts AS01346FW
Summary of Contents for AllMounts AS01346FW
- Page 1 Note: The displays are installed by the numerical order given. CAUTION: DO NOT EXCEED RATED LISTED WEIGHT. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! 300x300/400x200 55" AS01346FW 400x400/600x400 50kgx3 50kgx3 Note: The angle of displays are adjusted by the numerical order given. (110lbsx3) (110lbsx3) 300x300/400x200 55"...
- Page 2 D8 washer (x4) • Always use an assistant or mechanical lifting equipment to safely lift and position the equipment. Component (AS01346FW only) Component (AS01346FF only) • Tighten screws firmly, but do not over tighten. Over tightening can cause damage to the items, This greatly reduces their holding power.
- Page 3 1. Assembling the Base 4. Installing the Covers Note: With the brake wheels facing forward. Attach the left and right base to the middle base using the appropriate screws. Tighten all screws with an Allen key. 2. For the model AS01K installation 5.
- Page 4 7. Installing the Adapter Brackets Tighten all screws to secure them with an Allen key. X+5mm (X=Height of display) Top of the display X+5mm (X=Height of display) 7-1 For Flat Back Screens M-A/M-B/M-C 6. Installing the Top Cover Attach the top cover to the column using the appropriate screws.
- Page 5 7-2 For Recessed Back Screens or to Access A/V Inputs M-C M-D/M-E M-D/M-E M-D/M-E Use the padlocks to prevent the displays from being stolen (The padlocks are not included). Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screens. •...
- Page 6 10. Cable Management Insert the cable clamps horizontally into the plate slots, then turn the cable clamps to the vertical to secure them. If the displays tilted down, rotate the adjustment screws as shown in figure. down Run the cables through the cable clamps and the rubber strip.
- Page 7 12. Multi-screen Combination Solution 11. Adjustment Loosen the screws in the plastic covers in order to remove the plastic covers. +3° -3° Remove the screws attaching the front of the universal plates. Loosen the screws in the connecting fittings in order to slide the connecting attachments to both sides of the connecting fittings.
- Page 8 X+5mm Insert the connecting fittings (X=Height of display) to the appropriate position along the universal plates rails. X+5mm (X=Height of display) Note: The displays are installed by the numerical order given. Note: The position which the connecting fittings insert to the universal plate is Note: Make sure that the determined by the size of displays.
