Read This Manual

Manitowoc Food Service developed this manual as a
reference guide for the owner/operator and installer of
this equipment. Please read this manual before
installation or operation of the machine. A qualified
service technician must perform installation and start-up
of this equipment, consult Section 5 within this manual
for service assistance.
If you cannot correct the service problem, call your
Manitowoc Beverage Equipment (MBE) Service Agent
or Distributor. Always have your model and serial
number available when you call.
Your Service Agent ____________________________
Service Agent Telephone Number_________________
Your Local MBE Distributor ______________________
Distributor Telephone Number____________________
Model Number _______________________________
Serial Number ________________________________
Installation Date ______________________________

Unit Inspection

Thoroughly inspect the unit upon delivery. Immediately
report any damage that occurred during transportation to
the delivery carrier. Request a written inspection report
from a claims inspector to document any necessary
claim.
!
PERSONAL INJURY POTENTIAL
Do not operate equipment that has been misused,
abused, neglected, damaged, or altered/modified
from that of original manufactured specifications.
Part Number 020001552 5/11
General Information
Warning
Section 1

Model Numbers

This manual covers the following models:
Post Mix Soda Refrigeration Unit

How to Read a Model Number

Condenser
Model Prefix
2803 & SC180 - 1/3 hp
11M & SC340 - 1/2 hp
44M & SC1000 - 1 hp
44E - 1 hp, TUV Approved
50M & SC2000 - 2.2 hp
A - Air-cooled
AX - Air-cooled, international
R - Remote
RX - Remote, international
W - Water-cooled
WX - Water-cooled, international
General Information
11MA04B
Type
Model Base
11M A 04 B
04 - R404a refrigerant
Model Suffix
B - Reserve Ice Bank
T - TUV approved
carbonator tank
Q/T - Quick Trip
1-1
