Installation

Installer Instructions

Important
The remainder of these instructions is to be
completed by an authorized Multiplex Installer.
These equipment instructions are intended to assist
qualified personnel in the unpacking, locating and the
initial operation of the Multiplex Beverage Equipment
Post Mix Refrigeration Unit.
Important
This publication must be saved for future reference.
Read instructions before attempting installation.

PREPARATION

The Multiplex Beverage Equipment Post Mix
Refrigeration Unit is pre-assembled in the factory and
requires minimum installation.
For future reference or to be used when ordering parts,
record the Model Number, Serial Number, Part Numbers
of Unit, Condenser (if remote), Towers, etc., and Date of
Installation on the inside of this Manual. Leave manual
on site in a safe place. Do not discard manual.

SPECIFICATIONS

Model Volt/Cycle/Phase
11M
2-6
Minimum Circuit Amps
120/60/1
230/50/1
Ambient Location Requirement
This equipment is rated for indoor use only. It will not
operate in sub-freezing temperature. In a situation when
temperatures drop below freezing, the equipment must
be turned off immediately and properly winterized.
Contact the manufacturer for winterization process.

Electrical

GENERAL

All wiring must conform to local, state and national
codes.

MINIMUM CIRCUIT AMPACITY

The minimum circuit ampacity is used to help select the
wire size of the electrical supply. (Minimum circuit
ampacity is not the beverage/ice machine's running amp
load.) The wire size (or gauge) is also dependent upon
location, materials used, length of run, etc., so it must be
determined by a qualified electrician.

ELECTRICAL REQUIREMENTS

Refer to Ice Machine Model/Serial Plate for
voltage/amperage specifications.
Breaker
21.5
10.7
! Warning
Compressor
30A
16A
Part Number 020001552 5/11
Section 2
1/2 hp
.97 kW
