Configuring Handheld Terminal Settings

Calibrating Touch Screen Alignment

Whenever the response of the touch screen is poor, or operation being executed does
not match with the location you are tapping on the touch screen, please recalibrate the
alignment of the touch screen using the following method.
Press the "Fn" key and then press the "4" key after confirming that "F" is displayed
•
in the lower right corner of the screen. The following screen is displayed.
∗ You can also display this screen by navigating as follows:
Start " Settings " System " Screen " Align Screen
Press the stylus against the center of the target mark (+ mark) as indicated on the
•
screen.
After the calibration is complete, the terminal resumes a screen automatically
according to the method carried out to initiate the calibration.
If you start the calibration by pressing "Fn" and "4" keys, the terminal resumes Start
screen, or General tab screen of Settings mode which is the screen one before align
screen of Settings mode if you initiate by navigating to the icons.
E-22
