  • Page 1 MagicSafe MSG150 Gasmelder 59 Gasalarm Montage- und Bedienungsanleitung Montagehandleiding en gebruiksaanwijzing 19 Gas detector 69 Gasalarm Installation and Operating Manual Monterings- og betjeningsvejledning 29 Détecteur de gaz 79 Gasvarnare Instructions de montage et de service Monterings- och bruksanvisning 39 Alarma de gas 88 Gassalarm Instrucciones de montaje y d’uso...
  • Page 2 Hause WAECO. Bestellen Sie einfach unsere Kataloge kostenlos und unverbind- lich unter der Internetadresse: www.waeco.de We will be happy to provide you with further information about WAECO products. Please order our free catalogue with no obligation to buy on our homepage: www.waeco.com...
  • Page 3 MagicSafe MSG150...
  • Page 4 MagicSafe MSG150...
  • Page 5 MagicSafe MSG150...
  • Page 6 MagicSafe MSG150 RV-AMP-SW 12 V/24 V...
  • Page 7 MagicSafe MSG150 MS-620 (31) (30) 12 V/24 V...
  • Page 8 MagicSafe MSG150 gr/ws gn/rt MS-650 gn/rt rt/ge gr/ge bl/ge rt/sw bl/rt (31) (30) 12 V/24 V...

  • Page 9: Table Of Contents

    Notes on using the operating manual MagicSafe MSG150 Please read this manual carefully before mounting and starting up the device and store the manual in a safe place. If the device is resold, this operating manual must be handed over to the purchaser along with it.

  • Page 10: Safety And Installation Instructions

    Safety and installation instructions MagicSafe MSG150 Please observe the following safety instructions. Safety and installation instructions Caution! WAECO International will not be held liable for claims for damage resulting from the following: – Installation errors – Damage to the device resulting from mechanical influences and overvolt- –...

  • Page 11: Technical Description

    Technical description MagicSafe MSG150 Technical description The MSG-150 gas detector can be used as a warning device in many areas to detect gases with a narcotic effect before they can take effect. MSG-150 contains a sensor and an acoustic signal generator and is connected to a 12/24 V DC voltage supply, e.g.

  • Page 12: Connecting The Gas Detector

    Connecting the gas detector MagicSafe MSG150 Mounting the gas detector Note the following information when selecting a location to mount the gas detector: Note the length of the cable. The gas detector should be mounted in the vicinity of the sleeping area at the height of the mattress.
  • Page 13 Connecting the gas detector MagicSafe MSG150 Permanently wiring the MSG-150 If you wish to give the gas detector a permanently wired connection and switch it on with the RV-AMP-SW additional switch, please use the circuit diagram 9, page 6. ➤...
  • Page 14 Connecting the gas detector MagicSafe MSG150 In combination with MS-620 or MS-650 If you wish to use the gas detector in combination with MS-620, please use the circuit diagram a, page 7 MS-650, please use the circuit diagram a, page 7...

  • Page 15: Operating The Gas Detector

    Operating the gas detector MagicSafe MSG150 Operating the gas detector To avoid false alarms caused by cooking, using deodorants, heavy smoking and alcohol consumption, the vehicle should be ventilated thoroughly before retiring to bed and then the gas detector should be switched on.

  • Page 16: Alarm

    Alarm MagicSafe MSG150 If an alarm occurs, an acoustic signal sounds over the internal siren and the red LED (8 3, page 5) glows. If the MS-620SI external siren is connected, an additional acoustic signal sounds over the external siren.

  • Page 17: Troubleshooting

    Troubleshooting MagicSafe MSG150 Troubleshooting If the device is not ready for operation (the green LED does not glow), proceed as follows: ➤ Make sure the power supply is 12 or 24 V DC. If the voltage is less than this, or the voltage supply has been interrupted, the gas detector does not function.

  • Page 18: Guarantee

    Our general guarantee conditions apply. If the product is defective, please return it to the WAECO branch in your country (see the back of the instruction manual for the addresses) or to your specialist dealer. For repair and guarantee processing, the following documents...
  • Page 20 Dometic WAECO International GmbH Hollefeldstraße 63 · D-48282 Emsdetten ℡ +49 (0) 2572 879-195 · +49 (0) 2572 879-322 Mail: info@waeco.de · Internet: www.waeco.de Europe Overseas + Middle East Dometic Austria GmbH WAECO Italcold SRL WAECO Pacific Pty. Ltd. Neudorferstrasse 108 Via dell’Industria, 4/0...
