  • Page 1 AXT630/AXT631 Antenna Distribution System Distributeur d’antenne AXT630 et AXT631 Sistemas de distribución de antenas AXT630 y AXT631 Sistemas de Distribuição de Antena AXT630 e AXT631 © 2011 Shure Incorporated 27A15023 (Rev. 3) Printed in USA...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 14. REFER all servicing to qualified service personnel. Servicing is required when the ap- paratus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been 1. READ these instructions. exposed to rain or moisture, does not operate normally, or has been dropped. 2. KEEP these instructions. 15. DO NOT expose the apparatus to dripping and splashing. DO NOT put objects filled with 3. HEED all warnings. liquids, such as vases, on the apparatus. 4. FOLLOW all instructions. 16. The MAINS plug or an appliance coupler shall remain readily operable. 5. DO NOT use this apparatus near water. 17. The airborne noise of the Apparatus does not exceed 70dB (A). 6. CLEAN ONLY with dry cloth. 18. Apparatus with CLASS I construction shall be connected to a MAINS socket outlet with a 7. DO NOT block any ventilation openings. Install in accordance with the manufacturer’s protective earthing connection. instructions. 19. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or 8. DO NOT install near any heat sources such as radiators, heat registers, stoves, or other moisture. apparatus (including amplifiers) that produce heat. 20. Do not attempt to modify this product. Doing so could result in personal injury and/or 9. DO NOT defeat the safety purpose of the polarized or groundingtype plug. A polarized product failure.

  • Page 5: Included Components

    ® ing ranges and attenuation. To maximize use of available RF spectrum, two models of the Antenna Distribution System are available. The AXT630 covers a frequency range of 470-698 MHz and the AXT631 covers a frequency range of 606-814 MHz.

  • Page 6: Controls And Connectors

    Controls and Connectors power AXT631 606-814 MHz Antenna Distribution Ampli er AXT631 RF outputs RF outputs antenna 12.7V 150 mA cascade Input 100-240 V ~ 50/60 Hz 0.8A max. Output 100-240~ (5.8A max. outlet loaded) 5A max. 50/60 Hz UNSW. PoE Class 1 ①...

  • Page 7: Antenna System

    Antennas The AXT630 and AXT631 are compatible with front-mounted antennas or with remote-mounted antennas. When using the input band filtering function, select an antenna with bandwidth to cover the filter range. Installing Front-mounted Antennas Mounting the antennas on the front panel improves system performance by providing a clear signal path for the RF signal. Use the supplied bulkhead adapt- er kit to install the antennas on the front panel.

  • Page 8: Troubleshooting

    For large configurations, multiple AXT630s or AXT631s can be layered to support several levels of signal distribution: • Two levels of antenna distribution are possible if the level 1 and level 2 AXT630 or AXT631 have the Cascade ports activated.

  • Page 9: Utility Menu

    Utility Menu Press and hold both arrow keys to enter and exit the utility menu, which is used to access network and display settings. hold both arrow keys IP Address Mode: Automatic MAC (MAC Address) Display Invert This is the default setting for use with a DHCP Displays the MAC address, which is an embed- This changes the LCD menu from white text server, which automatically assigns an IP...

  • Page 10: Firmware Updates

    AXT 631: 606–814 MHz the Firmware Update Manager tool available in WWB6 software. Firmware is available for download from http://www.shure.com. AXT 630/ AXT631 Circuit Diagram Antenna In Cascade Out...
  • Page 11 Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. The CE Declaration of Conformity can be obtained from Shure Incorporated or any of its European representatives. For contact information please visit www.

  • Page 13: Composants Fournis

    6. Pour optimiser l’utilisation du spectre RF disponible, deux modèles de distributeur d’antenne sont disponibles. ® L’AXT630 couvre la plage de fréquences de 470 à 698 MHz et l’AXT631 la plage de fréquences de 606 à 814 MHz. Caractéristiques • Le filtrage d’entrée sélectionnable assure une protection contre les signaux forts hors bande au niveau système.

  • Page 14: Commandes Et Connecteurs

    Commandes et connecteurs power AXT631 606-814 MHz Antenna Distribution Ampli er AXT631 RF outputs RF outputs antenna 12.7V 150 mA cascade Input 100-240 V ~ 50/60 Hz 0.8A max. Output 100-240~ (5.8A max. outlet loaded) 5A max. 50/60 Hz UNSW. PoE Class 1 ①...
  • Page 15 Les antennes déportées offrent une plus grande souplesse de placement et peuvent améliorer les performances en procurant des chemins de transmission moins obstrués et augmentant ainsi la portée. Consulter http://www.shure.com pour obtenir des conseils et les meilleures pratiques concernant le montage des antennes déportées.

  • Page 16: Dépannage

    : • Deux niveaux de distribution d’antenne sont possibles si les ports en cascade des AXT630 ou AXT631 des niveaux 1 et 2 sont activés. • Jusqu’à 3 niveaux de distribution d’antenne sont possibles si seuls les ports en cascade des AXT630 ou AXT631 de niveau 1 sont activés.
  • Page 17 Menu utilitaire Appuyer sans relâcher sur les deux touches fléchées pour entrer dans le menu utilitaire ou pour en sortir. Ce menu permet d’accéder aux paramètres de réseau et d’affichage. maintenir les deux touches fléchées Mode d’adressage IP : Automatic Display Invert MAC (adresse MAC) C’est la valeur par défaut à...

  • Page 18: Mise En Réseau

    Caractéristiques- AXT630, AXT631 Antenna Sortie de répartition Distribution System Type de connecteur BNC (4 paires) Configuration Asymétrique, active Impédance 50 Ω Dimensions 44 mms x 483 mms x 366 mms (1,7 po x 19,0 po x 14,4 po), H x L x P Plage de réglage de gain...
  • Page 19 Tout changement ou modification n’ayant pas fait l’objet d’une autorisation expresse du fabricant peut entraîner la nullité du droit d’utilisation de l’équipement. La déclaration de conformité CE peut être obtenue auprès de Shure Incorporated ou de ses représentants européens. Pour les coordonnées, visiter www. shure.com La déclaration de conformité...

  • Page 21: Componentes Incluidos

    6 de los intervalos de filtrado y atenuación. Para maximizar el uso del espectro disponible de RF, se ofrecen dos modelos de sistema de distri- ® bución de antenas. El AXT630 cubre un intervalo de frecuencias de 470-698 MHz y el AXT631 cubre un intervalo de frecuencias de 606-814 MHz. Características •...

  • Page 22: Controles Y Conectores

    Controles y conectores power AXT631 606-814 MHz Antenna Distribution Ampli er AXT631 RF outputs RF outputs antenna 12.7V 150 mA cascade Input 100-240 V ~ 50/60 Hz 0.8A max. Output 100-240~ (5.8A max. outlet loaded) 5A max. 50/60 Hz UNSW. PoE Class 1 ①...
  • Page 23 Antenas Las unidades AXT630 y AXT631 son compatibles con las antenas montadas en la parte delantera o con antenas de montaje remoto. Cuando usa la función de filtro de banda de entrada, seleccione una antena con banda ancha para cubrir el rango del filtro.

  • Page 24: Localización De Averías

    • Dos niveles de distribución de antena son posibles si los niveles 1 y 2 de AXT630 o de AXT631 tienen activados los puertos de conexión en cascada. • Hasta 3 niveles de distribución de antenas son posibles si el nivel 1 de AXT630 o AXT631 tiene activados los puertos de conexión en cascada.

  • Page 25: Menú De Utilidades

    Menú de utilidades Mantenga oprimidas ambas teclas de flecha para entrar y salir del menú de utilidades, que se utiliza para acceder a los ajustes de red y de pantalla. mantenga oprimidas am- bas teclas de flecha Modo de dirección IP: Automatic MAC (dirección MAC) Display Invert Este es el valor por omisión para uso con un...

  • Page 26: Actualizaciones Del Firmware

    Para aprovechar las mejoras de diseño, las nuevas versiones del firmware se pueden cargar e instalar con la herramienta Firmware Update Manager disponible en el soft- ware WWB6. El firmware se puede descargar de http://www.shure.com. AXT 630/ AXT631 Circuit Diagram Antenna In...
  • Page 27 Los cambios o modificaciones que no tengan la aprobación expresa del fabricante podrían anular su autoridad para usar el equipo. La declaración de homologación de CE puede obtenerse de Shure Incorporated o de cualquiera de sus representantes europeos. Para información de con- tacto, por favor visite www.shure.com...

  • Page 28: Instruções De Montagem

    ® maximizar o uso do espectro de RF disponível, estão disponíveis dois modelos do Sistema de Distribuição de Antena. O AXT630 cobre a faixa de frequên- cias de 470 a 698 MHz e o AXT631 cobre a faixa de frequências de 606 a 814 MHz.
  • Page 29 Controles e Conectores power AXT631 606-814 MHz Antenna Distribution Ampli er AXT631 RF outputs RF outputs antenna 12.7V 150 mA cascade Input 100-240 V ~ 50/60 Hz 0.8A max. Output 100-240~ (5.8A max. outlet loaded) 5A max. 50/60 Hz UNSW. PoE Class 1 ①...
  • Page 30 As antenas remotas proporcionam maior flexibilidade ao posicionamento das antenas e podem melhorar o desempenho por proporcionar uma transmissão com menos obstruções e uma faixa de extensão. Consulte http://www.shure.com para ver dicas e melhores práticas para antenas de montagem remota.

  • Page 31: Resolução De Problemas

    Em configurações grandes, diversos AXT630 ou AXT631 podem ser superpostos para suportar diversos níveis de distribuição de sinal. • Dois níveis de distribuição de antena são possíveis se o AXT630 ou AXT631 de nível 1 ou nível 2 estiver com as portas em cascata ativadas.
  • Page 32 Menu Utilitário Mantenha pressionadas as duas teclas de seta para entrar e sair do menu utilitário, que é utilizado para acessar as configurações da rede e do mostrador. mantenha pressionadas as duas teclas de seta IP Address Mode (Modo de Endereço IP): MAC (Endereço MAC) Front Panel Lock Automatic...
  • Page 33 606–814 MHz AXT 631: melhorias no projeto, novas versões de firmware podem ser carregadas e instaladas utilizando a ferramenta Firmware Update Manager disponível no software WWB6. O firmware pode ser baixado em http://www.shure.com. AXT 630/ AXT631 Circuit Diagram Antenna In Cascade Out...
  • Page 34 Alterações ou modificações não expressamente aprovadas pelo fabricante podem anular a autorização do usuário para a operação do equipamento. A Declaração de Conformidade da CE pode ser obtida da Shure Incorporated ou de qualquer um dos seus representantes europeus. Para informações de contato, visite www.shure.com A Declaração de Conformidade da CE pode ser obtida em: www.shure.com/europe/compliance...
  • Page 36 United States, Canada, Latin Asia, Pacific: Europe, Middle East, Africa: America, Caribbean: Shure Asia Limited Shure Europe GmbH Shure Incorporated 22/F, 625 King’s Road Jakob-Dieffenbacher-Str. 12, 5800 West Touhy Avenue North Point, Island East 75031 Eppingen, Germany Niles, IL 60714-4608 USA...
