User's guide
''SEFE'' series
Electric furnace
This guide must be read carefully by the installer.
Then, the installer must give it to the user.
(Replacement component list included)
This unit is approved
according to the Canadian
standards and is intended
for the Canadian market
This unit complies with
the CSA standards
For further information or to consult this guide online, please visit our Web site.
INS_SEFE-U 0110
Advertisement
Table of Contents
Related Manuals for Stelpro SEFE Series
Summary of Contents for Stelpro SEFE Series
- Page 1 User’s guide ‘‘SEFE’’ series Electric furnace This guide must be read carefully by the installer. Then, the installer must give it to the user. (Replacement component list included) This unit is approved according to the Canadian standards and is intended...
- Page 2 WARNING WARNING WARNING WARNING Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them handy for future reference. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this product. This product must be installed by a qualified person and connected by a certified electrician, according to the electrical and building codes effective in your region.
-
Page 3: Operation
OPERATION The SEFE furnace is equipped with a user-friendly control panel. It includes five buttons and seven pilot lights (see explanations below). Legend 1- LOW SPEED CONTINUOUS VENTILATION button: allows the selection of the low speed continuous ventilation mode. 2- LOW SPEED CONTINUOUS VENTILATION pilot light: indicate that the low speed continuous ventilation mode is activated. 3- HIGH SPEED CONTINUOUS VENTILATION button: allows the selection of the high speed continuous ventilation mode. -
Page 4: Preventive Maintenance
MAINTENANCE N.B. In order for the warranty to be valid, the unit must be cleaned regularly. Moreover, a qualified technician must examine your furnace on a regular basis. Cut off power supply at circuit breaker/fuse before cleaning the unit. Use a soft rag for dusting. When cleaning, use only a damp rag and non-abrasive dish soap. Do not use abrasive or chemical cleaners because they can damage the finishing. - Page 5 REPLACEMENT COMPONENT LIST #REF. #PART DESCRIPTION ELF-SEF0521 ELEMENT ASSEMBLY 5 KW ELF-SEF0421 ELEMENT ASSEMBLY 4 KW ELF-SEF0221 ELEMENT ASSEMBLY 2 X 2.5 KW BLO-004 SQUIRREL CAGE & BLOWER 10-8 FOR 10 TO 23 KW DETAIL B BLO-005 SQUIRREL CAGE & BLOWER 12-11 FOR 27 & 30 KW MO-037 MOTOR 1HP, 208/240V, 1075 RPM, 3 SPEEDS, SUPPORT INCLUDED MO-036-1...
-
Page 6: Limited Warranty
Moreover, it does not cover the cost of disconnection, transport, and installation. The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original warranty period.
