This section must be read carefully by the installer. The installer must also read the user’s guide since it contains other important information. For further information or to consult this guide online, please visit our website at www.stelpro.com INSSFEU0914...
Page 2
waRning Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them handy for future reference. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this product.
operation ConTrol pAnel 9 10 tHERmoStat HigH/HaUtE StandaRd Low/BaSSE modES leGenD 1. ConTInUoUS VenTIlATIon button: provides the 7. ConTInUoUS HeATInG button: allows the selection of the selection of the high or low speed continuous ventilation mode. maximum or minimum continuous heating mode. 2.
HeAT pUMp If a heat pump is installed in your central heating system, the Stelpro electric furnace offers the installer two types of installations: type ”A” or type ”B”. Installation ”A” must be selected when the heat pump is installed After the furnace (air supply), and installation ”B” must be selected when the heat pump is installed Before the furnace (air return), as shown in the next picture.
Page 5
The heat pump can operate all year and allows the user to make energy savings due to the plenum temperature regulation function (exclusive to Stelpro). This function ensures a constant temperature into the plenum and the ducts. When it is cold, the heating capacity of the heat pump is reduced.
Page 6
MoDeS The user can select two different heating modes by pressing the button located in the middle of the control panel (item #4 in the control panel picture). The two modes affect the heating demand and the functions when used with the heat pump and the STANDARD mode described previ- ously.
maintenance AIr FIlTer N.B. In order for the warranty to be valid, the unit must be cleaned regularly. Excessive dust or dirt accumulation can block the airflow, forcing the Cut off power supply at circuit breaker/fuse before cleaning the unit to work harder to maintain the desired temperature. Therefore, it unit.
ConTrol CArD AUToDIAGnoSTIC The control card of the furnace is equipped with a pilot LED that allow easy and quick diagnostic of its essential functions. The yellow LED is located at the top right side of the control panel (item #10 of the control panel picture). The pilot LED will start to blink continuously when an electrical problem occurs.
Page 9
replacement component list REF. # PART # DESCRIPTION ELF-SFE0221-1 ELEmENT ASSEmBLY SFE 2.5KW/240V/1Ph 11’’ LONg ELF-SFE0221-2 ELEmENT ASSEmBLY SFE 2.5KW/240V/1Ph 14’’ LONg ELF-SFE0521-1 ELEmENT ASSEmBLY SFE 5KW/240V/1Ph 11’’ LONg ELF-SFE0521-2 ELEmENT ASSEmBLY SFE 5KW/240V/1Ph 14’’ LONg BLO-004 SQUIRREL CAgE & BLOWER 10-8 BLO-005 SQUIRREL CAgE &...
Stelpro reserves the right to examine or to ask one of its representatives to examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase price or repair a defective part.
