S
PECIFICATIONS
MAXIMUM CAPACITY (DRY WEIGHT)
BASKET (TUMBLER) DIAMETER
BASKET (TUMBLER) DEPTH
BASKET (TUMBLER) VOLUME
BASKET (TUMBLER) MOTOR
BLOWER MOTOR
CABINET WIDTH
CABINET DEPTH
CABINET HEIGHT
EXHAUST CONNECTION
HEAT INPUT
AIRFLOW @ 60 HZ
AIRFLOW @ 50 HZ
S.A.F.E. WATER CONNECTION
VOLTAGE AVAILABLE
NET WEIGHT
INLET PIPE CONNECTION
VOLTAGE AVAILABLE
NET WEIGHT
Voltage kW
208 4.1
208 6.1
230 5.0
230 7.4
230/240 5.4
230/240 8.1
380 6.8
400 7.5
416 8.1
Shaded areas are stated in metric equivalent
113191-2
________________
20 lbs 9 kg
25.75" 65.4 cm
24" 60.95 cm
7.5 cu ft 0.21 cu m
1/4 hp 0.19 kW
1/8 hp 0.1 kW
68.6 cm
27"
77.7 cm
30.59"
108.6 cm
42.25"
4" 10.2 cm
40,000 Btu/hr 10,080 kcal/hr
230 cfm 6.51 cmm
200 cfm 5.7 cmm
3/4"-11.5 NH
120v, 208v, 230/240v / 60 Hz / 1ø
230/240v / 50 Hz / 1ø
246.5 lbs 111.8 kg
3/8" M.N.P.T.
208v, 230/240v / 60 Hz / 1ø
230/240v / 50 Hz / 1ø
380v, 400v, 416v / 50 Hz / 3ø
239.5 lbs 108.6 kg
Oven Size
Btu/hr kcal/hr
13,993 3,526
20,819 5,246
4,300
17,065
25,255 6,364
18,430 4,644
27,644 6,966
5,848
23,208
6,450
25,597
6,966
27,644
1/22/04
Note
ADC reserves the right to make changes in
!
specifications at any time without notice or obligation.
3
