1.3 Network Architecture

Figure 1-4 Networking diagram of the eircom F2000 eFibre Modem
Issue: 01 (2014-09-30)
Interfaces Description
and buttons
USB interface Which is used to connect a USB device, such as a data
card, USB storage device or a USB printer.
The maximum voltage/current output from the USB
port is 5 V/0.8 A. That is, the input voltage/current of
the USB device connected to the USB port cannot
exceed 5 V/0.8A. Otherwise, the eircom F2000 may
not work correctly.
Copper pair
