Indicator
WiFi
VoIP
LAN1 ~
LAN4
USB
Issue: 01 (2014-09-30)
Status Description
On The WLAN connection is set up, but no data is
being transmitted.
Fast Blinking The WLAN connection is set up, and data is
(2Hz) being transmitted.
Slow Flashing A wireless client, such as a computer installed
with a wireless network adapter, is connecting to
(1Hz)
the eircom F2000 using the WPS function. This
process lasts for no longer than 120 seconds.
Off The WLAN function is disabled.
On The eircom F2000 is registered with the SIP
(Session Initiation Protocol) server, but no data is
being transmitted.
Blinking The VoIP connection is set up, and data is being
transmitted.
No VoIP connection is established.
Off
On The eircom F2000 is connected to a device
properly.
Blinking Data is being transmitted between the eircom
F2000 and the device connected.
Off No connection is set up on the port.
On The USB connection is successfully established
in USB host mode, but no data is being
transmitted.
Blinking A USB device is connected to the USB port, and
data is being transmitted on the USB port.
The USB port is not connected.
Off
