Safety, Operation and Maintenance Manual
R311T-T4F
69178 – R311T-T4F, Kubota
WARNING: If incorrectly used this machine can cause severe
injury. Those who use and maintain this machine should be
trained in its proper use, warned of its dangers and should
read the entire manual before attempting to set up, operate,
adjust or service the machine.
GB
RJL 100 August 2014
United
Kingdom
Rotary Mower with folding ROPS
™
®
WARNING
V2403-CR-T, 4WD
4280331-GB-Rev A
When Performance Matters.
™
Advertisement
Table of Contents
Related Manuals for Jacobsen R311T-T4F
Summary of Contents for Jacobsen R311T-T4F
- Page 1 Safety, Operation and Maintenance Manual R311T-T4F Rotary Mower with folding ROPS ™ ® 69178 – R311T-T4F, Kubota V2403-CR-T, 4WD WARNING WARNING: If incorrectly used this machine can cause severe injury. Those who use and maintain this machine should be trained in its proper use, warned of its dangers and should read the entire manual before attempting to set up, operate, adjust or service the machine.
-
Page 2: Table Of Contents
State of © Copyright 2014, Jacobsen, A Textron Company. “All rights California to cause cancer and birth reserved, including the right to reproduce this material or portions defects or other reproductive harm. thereof in any form.”... -
Page 3: Introduction 2
2Introduction IMPORTANT ______________________________________________________________ The Jacobsen R311T with a Diesel engine is a self propelled rotary mower. The hydraulic systems are for the traction drive, steering, lift - lower and the cutting unit drive. If you follow all instructions in this manual, you increase the life of your mower and keep its maximum performance. -
Page 4: Product Identification
2 INTRODUCTION PRODUCT IDENTIFICATION_________________________________________________ Mower Serial number plate Gross weight (Kg) 11524 WILMAR BLVD, ® Engine Power (Kw) CHARLOTTE, NC 28273 A Textron Company PRODUCT OF U.S.A. 1-800-848-1636 (US) Date code Product number and Serial number Location of Mower Serial number plate The serial number plate (A) is found on the right side frame rail behind the wing deck mount. -
Page 5: Guidelines For The Disposal Of Scrap Products
Add items that can not be easily separated into different materials to the “General discarded materials” area. • Do not burn the discarded materials Change the mower records to show that the mower is not in service and is discarded. Supply this serial number to Jacobsen Warranty Department to close their records. -
Page 6: Safety
Manuals in additional languages may be available on the Jacobsen or RansomesJacobsen website. Read all of the instructions for this mower carefully. Know the controls and the correct operation of the equipment. - Page 7 SAFETY 3 3.1.3 OPERATION Never operate the engine without enough ventilation or in an enclosed area. The carbon monoxide in the exhaust fumes can increase to dangerous levels. Never carry passengers. Keep other persons or animals away from the mower. Disengage all drives and engage the parking brake before you start the engine.
- Page 8 ROPS. Do not remove the ROPS from the mower. Jacobsen must approve any changes to the ROPS. 3.1.5 SAFE HANDLING OF FUELS The fuel and the fuel vapors are flammable. Use caution when you add the fuel to the mower. The fuel vapors can cause an explosion.
- Page 9 Replace worn or damaged parts for safety. Replace damaged or worn decals. Only use parts, accessories and attachments approved by Jacobsen. To decrease the fire hazard, remove materials that burn from the engine, muffler, battery tray and fuel tank area.
-
Page 10: Important Safety Notes
3. Keep persons and animals away from the area of operation. 4. Never carry passengers. 5. Never operate the equipment without a correctly fastened grass deflector in position. If additional information or service is needed, contact your Authorized Jacobsen Dealer. Your Dealer knows the current methods to service this equipment. -
Page 11: Specifications 4
SPECIFICATIONS 4 4Specifications ENGINE SPECIFICATIONS __________________________________________________ R311T Make Kubota Model V2403-CR-T-E4B Type Four cycle, liquid cooled, Diesel Number of Cylinders Bore and Stroke 3.43 in. (8.7 cm) x 4.03 in. (10.24 cm) Total Displacement 148.5 in (2.434 l) Combustion System Direct Injection Intake System Turbocharged... -
Page 12: Dimensions And Weights
4 SPECIFICATIONS DIMENSIONS AND WEIGHTS ________________________________________________ R311T A - Width of Cut (Front and both 134 inch (340.3 cm) wings) B - Maximum Width 139 inch (353.0 cm) C - Transport Width 93.5 inch (237.5 cm) D - Height ROPS frame in the 84 inch (213.4 cm) vertical position E - Height ROPS frame folded... - Page 13 SPECIFICATIONS 4...
-
Page 14: Mower Specification
4 SPECIFICATIONS MOWER SPECIFICATION ___________________________________________________ Battery: 12V, 560 CCA, Group AABM #75NF Service Brake: Dynamic braking through the traction circuit Parking Brake: Integrated in wheel motor, hydraulic release Fuel Tank: 20 U.S. Gallons (75.7 l) Hydraulic Tank: 16 U.S. Gallons (60.57 l) Hydraulic Fluid: SAE 10W30 Return Filter:... -
Page 15: Vibration Level
SPECIFICATIONS 4 VIBRATION LEVEL_________________________________________________________ The mower was tested for hand and arm vibration levels. The operator was in the normal position to drive the vehicle, with two hands on the steering mechanism. The engine was in operation and the cutting device was in rotation, while the mower was not moving. -
Page 16: Slopes
4 SPECIFICATIONS SLOPES _________________________________________________________________ DO NOT USE ON SLOPES GREATER THAN 16.5°. The 16.5° slope was calculated with static stability measurements according to the requirements of BS EN ISO 5395-3. CUTTING UNIT SPECIFICATION _____________________________________________ R311T Blade Length 22.87 in. (58.1 cm) Number of blades Height of cut 1 to 5-1/2 in. -
Page 17: Accessories
SPECIFICATIONS 4 ACCESSORIES____________________________________________________________ 4.9.1 CANOPY / SUN SHADE _____________________________________________________ Product number 68127 4.9.2 MULCHER KIT ____________________________________________________________ Product Number 69174 4.9.3 REPLACEMENT BLADES ___________________________________________________ Left Hand Blade 4186581 Right Hand Blade 4186582 Left Hand Right Hand Blade Blade... -
Page 18: Support Literature
4.9.6 CAREFREE TIRE KIT_______________________________________________________ Kit number 2811453 Individual Tire Replacement 2811454 4.10 SUPPORT LITERATURE ____________________________________________________ Contact your Jacobsen Dealer for a complete listing of literature available for your mower. Safety, Operation, & Maintenance Manual: 4280331 Mower Parts Manual: 4280334 Engine Parts Manual: 4290893... -
Page 19: Declaration Of Conformity
▪ Uzņēmuma nosaukums un pilna ražotāja adrese ▪ Verslo pavadinimas ir pilnas Jacobsen, A Textron Company gamintojo adresas ▪ Isem kummerċjali u indirizz sħiħ tal-fabbrikant ▪ Nazwa firmy i pełny adres producenta ▪ Nome da empresa e 11524 Wilmar Blvd. - Page 20 4 SPECIFICATIONS Conforms to Directives ▪ В съответствие с директивите ▪ Splňuje podmínky směrnic ▪ Er i overensstemmelse med direktiver ▪ Voldoet aan de richtlijnen ▪ Vastab direktiividele ▪ Direktiivien mukainen ▪ Conforme aux directives ▪ Entspricht Richtlinien ▪ 2004/108/EC Ακολουθήστε...
- Page 21 ▪ Ort und Datum der Erklärung ▪ Τόπος και ημερομηνία δήλωσης ▪ A nyilatkozat kelte (hely és idő) ▪ Luogo e data della dichiarazione ▪ Jacobsen, A Textron Company Deklarācijas vieta un datums ▪ Deklaracijos vieta ir data ▪ Il-post u d-data tad-dikjarazzjoni ▪ Miejsce i data wystawienia deklaracji ▪...
- Page 22 Assinatura da pessoa com poderes para emitir a declaração em nome do fabricante, que possui a documentação Director of Engineering técnica, que está autorizada a compilar o processo técnico e que está estabelecida na Comunidade. Jacobsen, A Textron Company Semnătura persoanei împuternicite să elaboreze declaraţia în numele producătorului, care deţine documentaţia 11524 Wilmar Blvd, tehnică, este autorizată...
-
Page 23: Decals 5
DECALS 5 5Decals SAFETY DECALS __________________________________________________________ Understand the purpose of these decals. The decals are important to the safe operation of the mower. REPLACE THE DAMAGED DECALS IMMEDIATELY. DANGER Injury or death can occur from contact with the blade or from the objects discharged from the mower. - Page 24 5 DECALS WARNING To prevent injury, do not touch the muffler or muffler shield. The muffler temperatures can be more than 150° F (66° C). 4199140 WARNING Do not use the mower for towing. 4205183 WARNING Always use the seat belt with the ROPS frame in the vertical and locked position. WARNING 5002952 Always use the seat belt with the ROPS frame in the vertical and locked position.
- Page 25 DECALS 5 4181865 REV B WARNING • Read the manual. Do not allow persons without training to use the mower. • Keep the shields in position and hardware fastened. • Keep your hands, feet and clothing away from moving parts. •...
- Page 26 5 DECALS WARNING The charge filter is under pressure. To prevent injury, remove the filter slowly. 4181863 4239123 WARNING To prevent injury or death, never operate the mower without the seat hardware installed correctly. Read the manual for more information. Without the seat platform fastened, the seat can tilt suddenly when you make a sudden change in direction, when you operate on the slopes or when the mower is over turning.
-
Page 27: Instruction Decals
DECALS 5 WARNING To prevent injury when you fold the ROPS, use caution to prevent your fingers broken between moving and rigid parts of the ROPS. NOTICE WARNING This structure's Do NOT fold this ROPS proctective capability may be impaired by if a canopy is attached. - Page 28 5 DECALS Antifreeze THIS RADIATOR CONTAINS ANTI-FREEZE PROTECTED TO -26°F (-32°C) Mix equal par ts of clean water and a premium quality ethylene glycol based anti-freeze to maintain the boil over, r ust and corrosion protection. Drain and discard coolant year ly. Read manual for additional instr uctions.
- Page 29 DECALS 5 Weight Transfer Increase Decrease Guaranteed Sound Power Level Control Panel...
-
Page 30: Controls
6 CONTROLS 6Controls OPERATOR COMPARTMENT________________________________________________... -
Page 31: Control Panel
CONTROLS 6 CONTROL PANEL _________________________________________________________ 6.2.9 6.2.8 6.2.10 6.2.4 6.2.17 6.2.5 6.2.6 6.2.11 6.2.12 6.2.15 6.2.2 6.2.13 6.2.14 6.2.3 6.2.7 6.2.1 6.2.16... -
Page 32: Ignition Switch
6 CONTROLS 6.2.1 IGNITION SWITCH _________________________________________________________ The ignition switch has three positions, OFF, RUN and START. In the run position, the controller program is active and input and output circuits are monitored. START 6.2.2 PARKING BRAKE SWITCH__________________________________________________ To engage the parking brake, move the orange lock toward front of mower and press the front of the switch. - Page 33 CONTROLS 6 6.2.4 FRONT DECK LEVER ______________________________________________________ The front deck lever lifts and lowers the front deck. Front Deck Lever NOTICE The engine throttle must be at least 50% speed to lift or lower the decks. Press and release the lever until the front deck has lowered to the ground. If the PTO switch is in the ON position, the front deck blades will start to turn when the front deck is lowered.
- Page 34 6 CONTROLS 6.2.7 DPF REGEN INHIBIT SWITCH _______________________________________________ Press the rear of the switch to the INHIBIT position to prevent the DPF Regen cycle from starting. The Red light at front of switch will illuminate when switch is in the INHIBIT position. See 9.10 NOTICE If the DPF Regen cycle is prevented for too long of a period, a blockage of the DPF can occur.
-
Page 35: Pto Switch
CONTROLS 6 6.2.10 FILTER LIGHT MODULE ___________________________________________________ The filter light module has an amber fuel filter light and a red charge filter light. Fuel filter The fuel filter light indicates that moisture was sensed in the fuel. Check and replace the water separator and fuel filter elements as needed. -
Page 36: Cruise Control Switch
6 CONTROLS 6.2.14 4WD SWITCH ____________________________________________________________ The 4WD switch controls the operation of the 4WD traction system. The mower will automatically switch to 4WD with the PTO switch in the ON position. Put the switch in the center position for 2WD. When the mower is in motion, do not engage or disengage the 4WD system. - Page 37 CONTROLS 6 6.2.17 COMBINATION GAUGE ____________________________________________________ The combination gauge shows the hours of operation, the level of fuel and has six indicator lights to indicate the mower conditions. The hour meter in the center of the gauge shows the hours of operation of the mower.
-
Page 38: Traction Pedal
6 CONTROLS The red parking brake light indicates that the parking brake switch is in the ON position. Do not press the traction pedal with light illuminated. The red battery light indicates that the battery voltage was less than 11.5 volts for one minute. Return the mower to the service area. -
Page 39: Seat Controls
CONTROLS 6 SEAT CONTROLS _________________________________________________________ The seat has three controls to adjust for the operator. WARNING To prevent injuries, DO NOT adjust the seat while you operate the mower. Only adjust the seat with the mower stopped and parking brake engaged. Armrest Lift the seat position lever and move the seat backward or forward. -
Page 40: Operation
7 OPERATION 7Operation DAILY INSPECTION _______________________________________________________ CAUTION The inspection must be done each day when the engine is turned off and all fluids are cold. Lower the cutting units to the ground, engage the parking brake, stop the engine and remove the ignition key. Do a visual inspection of the mower. -
Page 41: Interlock System
OPERATION 7 INTERLOCK SYSTEM ______________________________________________________ The Interlock System prevents the engine to start unless the parking brake switch is in the ON position, the traction pedal is in the NEUTRAL position, cruise control switch is in the OFF position and the PTO switch is in the OFF (Down) position. -
Page 42: Operating Procedure
7 OPERATION OPERATING PROCEDURE __________________________________________________ WARNING This mower has a folding Roll Over Protection Structure (ROPS). Always wear the seat belt with the ROPS frame in the vertical and locked position. Never wear the seat belt with the ROPS in the folded position. If the mower is over turning and the ROPS is in the vertical and locked position, hold the steering wheel. -
Page 43: Starting The Engine
OPERATION 7 STARTING THE ENGINE ____________________________________________________ Start the engine with the operator in the seat, the PTO switch in the OFF position, the cruise control switch in the OFF position and the Glow parking brake switch in the ON position. Remove your foot from the Plug traction pedal. -
Page 44: Driving
7 OPERATION DRIVING _________________________________________________________________ Read and follow all safety instructions contained in this manual when you drive the mower. When you operate in the reverse direction, look behind you to make sure you have a clear path. IMPORTANT: Equipment must meet the current regulations to be driven on the public roads. Push the PTO switch to the OFF position and lift the cutting units to the transport position. -
Page 45: Mowing On Slopes
OPERATION 7 MOWING ON SLOPES ______________________________________________________ The mower is made to have good traction and to have good balance. Operate the mower with caution when you drive on a gradient. If you drive on wet grass, the traction and steering control of the mower is decreased. - Page 46 7 OPERATION How to calculate a slope: Tools Required: Level (A), either 1 yard, or 1 meter long. Tape measure (B). Use the level (A) and position it horizontally to measure the distance (C) with tape measure (B). Use the chart to calculate the slope angle or the percentage grade of the slope (D).
-
Page 47: Towing The Mower
Open mower. NOTICE When you tow the mower, do not drive more than 2 mph Brake (3.2 km/hr). Jacobsen recommends that you do not tow Release the mower for long distances. Lever Normal When the mower gets to the service area, close the bypass... -
Page 48: Maintenance And Lubrication Charts
8 MAINTENANCE AND LUBRICATION CHARTS 8Maintenance and Lubrication Charts MAINTENANCE CHART Mower Service Interval Chart Interval Item Section First 50 Hours • Replace engine oil See 9.3 • Replace engine oil filter See 9.3 • Replace hydraulic oil filter See 9.13 •... -
Page 49: Lubrication Chart
MAINTENANCE AND LUBRICATION CHARTS 8 LUBRICATION CHART _____________________________________________________ FLUID REQUIREMENTS ____________________________________________________ Fluid Requirements Quantity Type Engine Oil with Filter 10 Quart (9.5 liter) 10W-30 API Classification CJ-4 Hydraulic Oil with Filter 16 U.S. Gallon (60.5 liter) 10W-30 (Standard) GreensCare 68 (Optional) GreensCare 68 Plus (Optional) Radiator Coolant 8 Quart (7.6 liter) -
Page 50: Maintenance
• Refer to the Engine manual for specified maintenance intervals. If the injection pump, injectors or the fuel system need service, contact your Jacobsen Dealer. NOTICE The mower operates and cuts correctly at the preset governor setting. Do not change the engine governor setting... -
Page 51: Engine Oil
MAINTENANCE 9 ENGINE OIL ______________________________________________________________ Check engine oil level Check the engine oil level before you start the engine or at least five minutes after you stop the engine. Park the mower on a level surface. Remove the dipstick, clean the dipstick with a cloth and replace in position. -
Page 52: Engine Air Filter
9 MAINTENANCE ENGINE AIR FILTER _______________________________________________________ Check the service indicator each day. If the red band become visible in the window, replace the filter elements. Dust Valve Do not remove the elements to inspect or clean. Removal of Filter Housing the filter that is not necessary increases the risk of dust and other particles to enter the engine. -
Page 53: Fuel System
MAINTENANCE 9 FUEL SYSTEM ____________________________________________________________ Water Separator Hand Pump Vent If the water is not removed from the fuel, damage to the fuel-injection system can occur. When the fuel filter light on the filter light module is illuminated or every 100 hours, drain the water from the water separator. -
Page 54: Battery
9 MAINTENANCE BATTERY ________________________________________________________________ Before you service the battery, make sure the ignition switch is in the OFF position and the key is removed. CAUTION When you service the battery, always use the tools with insulation, wear protective glasses and protective clothing. Discard used batteries as shown in your local regulations. -
Page 55: Charge The Battery
MAINTENANCE 9 CHARGE THE BATTERY __________________________________________________________ WARNING Charge the battery in an area with good airflow. The battery can release hydrogen gas that is explosive. To prevent an explosion, keep any device that can cause sparks or flames away from the battery. When the battery charger is turned on, to prevent injury, stay away from the battery. -
Page 56: Diesel Particulate Filter
9 MAINTENANCE 9.10 DIESEL PARTICULATE FILTER ______________________________________________ During the operation of the mower, the level of particle material will increase in the Diesel Particulate Filter (DPF) system. The periodic Regen of the DPF system is needed to remove particle material. During an Active or Parked Regen, the engine will use more fuel. -
Page 57: Hydraulic Hoses
MAINTENANCE 9 Level 5 - High Exhaust Temperature light will flash quickly and the check engine light is illuminated. The engine power output is decreased significantly. An authorized Kubota Engine Service Center must clean the DPF before the mower is used. -
Page 58: Hydraulic Fluid
9 MAINTENANCE 9.12 HYDRAULIC FLUID ________________________________________________________ Drain and replace the hydraulic oil if one of the following occur. • Component failure • Water or foam is in the hydraulic fluid • The hydraulic fluid has a rancid odor (indication of high heat) •... -
Page 59: Wheel Mounting Procedure
Check and tighten the engine fan belt every 100 hours and replace the belt every 500 hours. Replace the clamps and hoses every two years. Have your Jacobsen Dealer check the cooling system if you need to add coolant more than one time a month or you add more than a quart of coolant at a time. -
Page 60: Folding Rops
9 MAINTENANCE 9.17 FOLDING ROPS ___________________________________________________________ A folding Roll Over Protective Structure (ROPS) is included with this mower. Inspect the ROPS periodically for loose hardware or damage. CAUTION Keep the ROPS hardware correctly fastened. Do not do welding operations, drill, change or bend the ROPS. Replace damaged ROPS. -
Page 61: Inspecting Blades
MAINTENANCE 9 9.18 INSPECTING BLADES ______________________________________________________ Every 50 hours of operation or when the cutting unit is removed from the mower, carefully inspect the blades to make sure the blades are in good condition. Replace any blade that has bends, grooves or cracks. Normal CAUTION Blade... -
Page 62: Electrical System
• Check the interlock system, fuses and circuit breakers at normal intervals. If the interlock system does not operate correctly and you can not correct the problem, contact an authorized Jacobsen Dealer. • Keep the wiring harness away from hot surfaces and moving parts. -
Page 63: Circuit Breakers
MAINTENANCE 9 9.20.2 CIRCUIT BREAKERS ______________________________________________________ Open the two latches and remove the access panel on the right-side console wall to check the circuit breakers. CB1 - 10 Amp Ignition Switch Circuit Breaker CB2 - 10 Amp Combination Gauge Circuit Breaker CB10 CB3 - 10 Amp 4WD-Cruise Control Circuit Breaker CB4 - 30 Amp Accessory Relay Circuit Breaker... -
Page 64: Care And Cleaning
Clean all plastic or rubber parts with a weak soap solution or use commercially available rubber cleaners. To keep the original high polish of the fiberglass parts, wax with a good grade of one-step cleaner wax. Repair damaged metal surfaces and use Jacobsen touch-up paint. Apply wax to the equipment for maximum paint protection. -
Page 65: Mower Storage
MAINTENANCE 9 9.22 MOWER STORAGE ________________________________________________________ General • Clean the mower and lubricate. Repair and paint damaged or open metal. • Inspect the mower, tighten all hardware, replace worn or damaged components. • Drain and fill the radiator. • Clean the tires and keep the mower so that the load is not on the tires. If the mower is not on the jack stands, check tires at normal intervals and add air when needed. -
Page 66: Adjustments
Always use the jack stands. A qualified technician must always do adjustments and maintenance. If the correct adjustments can not be made, contact your Jacobsen Dealer. Inspect the equipment according to the maintenance schedule and keep complete records. Keep the equipment clean. -
Page 67: Neutral Adjustment
ADJUSTMENTS 10 10.3 NEUTRAL ADJUSTMENT ___________________________________________________ The neutral adjustment is set at the factory on all new mowers and replacement pumps. Additional adjustment is not necessary unless the pump was disassembled for repair or service. Neutral adjustment is set at the drive pump. -
Page 68: Forward And Reverse Speed Adjustment
10 ADJUSTMENTS 10.4 FORWARD AND REVERSE SPEED ADJUSTMENT ______________________________ The forward and reverse speed adjustments are made at the traction pedal. Set the forward speed before you adjust the reverse speed. To adjust the forward speed - Make sure that the neutral adjustment is set. Rotate the mow speed stop to the transport position. -
Page 69: Neutral Switch Adjustment
ADJUSTMENTS 10 10.7 NEUTRAL SWITCH ADJUSTMENT ____________________________________________ Adjust the neutral switch after the neutral adjustment or forward speed adjustment is done. When the traction pedal is in the NEUTRAL position, the rod end bolt must be Sensing part of over the sensing part of the switch. If necessary, loosen switch hardware and switch adjust the position of the switch. -
Page 70: Steering Adjustments
10 ADJUSTMENTS 10.10 STEERING ADJUSTMENTS _________________________________________________ Adjust the Steering Toe-In. Turn the rear wheels to the straight position. Loosen the clamp bolts on both ends of the tie rod. Rotate the tie rod to get the correct toe-in. The toe-in must not be more than +1/16 inch (+ 0.15 cm). -
Page 71: Height Of Cut
ADJUSTMENTS 10 10.11 HEIGHT OF CUT___________________________________________________________ The height of cut for the cutting unit is adjusted from 1 to 5-1/2 inch (2.5-14.4 cm) in 1/2 inch (1.3 cm) steps. The height of cut result can be different from the heights given because of the condition of the turf and other conditions. NOTICE When cutting rough areas, a lower height of cut can cause scalping. - Page 72 10 ADJUSTMENTS Spacers Below Pivot Height of Cut Caster Arm Position Pin Mounting Position Block 1 inch (1.9 cm) 1-1/2 inch (3.8 cm) 2 inch (5.1 cm) 2-1/2 inch (6.3 cm) 3 inch (7.6 cm) 3-1/2 inch (8.9 cm) 4 inch (10.2 cm) 4-1/2 inch (11.4 cm) 5 inch (12.7 cm) 5-1/2 inch (13.3 cm)
-
Page 73: Level The Front Deck
ADJUSTMENTS 10 10.12 LEVEL THE FRONT DECK __________________________________________________ Before the front deck is leveled, inflate the mower tires and Front End caster wheels to the correct pressure. The deck level is of Blade related to the tire pressure. Front End Set the cutting height of the front mower to 5-1/2 in. -
Page 74: Torque Specification
Jacobsen uses Grade 5 (Inch) and Grade 8.8 (Metric) Plated bolts, unless a note is shown. Always check the marks on the head of the bolts for the bolt grade. For tightening plated bolts, use the value given for lubricated hardware. -
Page 75: Problem Solving 11
PROBLEM SOLVING 11 11Problem Solving 11.1 GENERAL ________________________________________________________________ The problem solution chart lists basic problems that can occur during start and operation of the mower. For complete information about the hydraulic and electrical systems, contact your Jacobsen Dealer. Problem Possible Cause Action... -
Page 76: Quality Of Cut
12 QUALITY OF CUT 12Quality of Cut 12.1 QUALITY OF CUT PROBLEM SOLVING _______________________________________ Make a “test cut” to check the performance of the mower before you start the repairs. This area must have turf conditions that are known and do not change across the area. This type of area allows an accurate inspection of the perfomance of the mower to be made. -
Page 77: Step Cutting
QUALITY OF CUT 12 12.3 STEP CUTTING____________________________________________________________ Step cutting occurs when grass is cut higher on one side of a cutting unit than the other side. Step cutting can occur when one cutting unit is higher than another cutting unit. The wear of mechanical parts or an incorrect roller adjustment can cause step cutting. -
Page 78: Scalping
12 QUALITY OF CUT 12.4 SCALPING _______________________________________________________________ Scalping is a condition in which areas of grass are cut shorter than the adjacent areas. The area can be light green or brown. A low HOC setting or turf that is not level can cause scalping. -
Page 79: Stragglers
QUALITY OF CUT 12 12.5 STRAGGLERS ____________________________________________________________ Stragglers are separated blades of grass the are not cut, or are cut incorrectly. TN0223 NOTE: Arrow indicates direction of travel. Probable Cause Remedy Edge of the cutting blade(s) are not sharp. Sharpen the blade(s). See 9.19 Cut (ground) speed is higher than normal Reduce the cut (ground) speed. -
Page 80: Streaks
12 QUALITY OF CUT 12.6 STREAKS ________________________________________________________________ A streak is a line of grass that is not cut. The cause of a streak can be a damaged blade. TN0224 NOTE: Arrow indicates direction of travel. Probable Cause Remedy Damaged blade(s). Replace the blade(s). -
Page 81: Windrowing
QUALITY OF CUT 12 12.7 WINDROWING ____________________________________________________________ Windrowing is the deposit of clippings increased at one end of cutting unit(s) or between cutting units. Windrowing can make a line in the direction of travel. TN0225 NOTE: Arrow indicates direction of travel. Probable Cause Remedy The grass is higher than the level at which the mower... -
Page 82: Mismatched Cutting Units
12 QUALITY OF CUT 12.8 MISMATCHED CUTTING UNITS ______________________________________________ Mismatched cutting units is a pattern of different cutting heights, that gives the grass a stepped cut appearance. THis appearance is normally because of a mismatched HOC (height-of-cut) adjustment from one cutting unit to another unit. - Page 83 NOTES 13 13Notes...
- Page 84 Europe & Rest of The World Except North & South America Ransomes Jacobsen Limited West Road, Ransomes Europark, Ipswich, IP3 9TT English Company Registration No. 1070731 www.ransomesjacobsen.com North & South America Jacobsen, A Textron Company 11108 Quality Drive, Charlotte, NC 28273, USA www.Jacobsen.com When Performance Matters. ™...
