Parts & Maintenance Manual
Underhållshandbok och reservdelslista
R-311T
Rotary Mower with folding ROPS
™
R-311T
Rotorgräsklippare med fällbar
™
skyddsram (ROPS)
69171 – Kubota
If incorrectly used, this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its
dangers and should read the entire manual before attempting to set up,
operate, adjust or service the machine
Om denna maskin används på fel sätt kan den orsaka svåra personskador.
De som använder och underhåller denna maskin ska utbildas i hur den
används korrekt, vara varnade för de förekommande riskerna och ska alltid
läsa hela handboken innan någon form av arbete utförs på eller med maskinen.
SE
GB
United
Sweden
Kingdom
V2403-M-T
®
WARNING
VARNING
4227700-SE-Rev.A
6
5
9
1 1
1 6
1 3
1 5
7
8
1 8
1 7
1 - I N C L U D E S I T E M S 3 - 1 6
1 9
3
1 0
4
When Performance Matters.
™

Advertisement

Chapters

Table of Contents
loading

Related Manuals for Jacobsen R-311T

Summary of Contents for Jacobsen R-311T

  • Page 1 4227700-SE-Rev.A 1 - I N C L U D E S I T E M S 3 - 1 6 Parts & Maintenance Manual Underhållshandbok och reservdelslista R-311T Rotary Mower with folding ROPS ™ R-311T Rotorgräsklippare med fällbar ™ skyddsram (ROPS) 69171 –...
