FRONT
1
1. Power Indicator
2. Volume/Power Control
3. FM Antenna (FM ANTENNA PART
NO. 188-YS7158001-E*)
4. Source Button/Indicator
5. EQ Button/Indicator
6. Skip 9 Button/Indicator
7. Preset Buttons/Indicators

LOCATION OF CONTROLS

2 3 4 5 6 7 8 9
O
SOURCE EQ
1 2 3
10
®p n
4 5
8. Play/Pause 4 ; Button/Indicator
9. Skip : Button/Indicator
10. Display
11. Carrying Handle
12. Select Control
13. BACK Button
14. OK Button
*Consumer Replaceable Part (See page 24 to order.)
6
11 12 1314
