Installation Preparation
CUTOUTS AND CLEARANCES
, Measure carefullg when cutting the countertop.
, Make sure sides of the opening are parallel and
rear and front cuts are exactlg perpendicular
(right angles) to the sides.
, Measure to be sure there is room for clearances
to the front edge of the countertop.
, Refer to cooktop installation instructions to be sure
that models fit into the base cabinets being used.
, Draw lines on the countertop to follow as a cutting
guide.
, Measure and mark cooktop and vent overlaps to be
sure there is enough fiat countertop depth.
• The cabinet side walls should be within 5-1/2" of the
vent bodg. The cabinet back wall should be within
4-1/2" of the vent bodg (refer to Creoi:ive Solutions.)
Cooktop Cooktop
o Measure the base cabinet width at the top and
bottom to ensure it meets the minimum width
requirements.
I MODEL I'A'MinimumWidth
PVBg8
]4"
ZVB36
PVB94
ZVB30 28-1/2"
Side View: Installed Vent
Front View: Installed Vent
30" COOKTOP AND DOWNDRAFT
COMBINATION
8-!/2"
The cooktop must be installed per manufacturer's
installation instructions.
INPORTANT: The countertop cutout depth requires
23-1/2" minimum flat countertop surface and 25"
minimum total countertop depth.
NOTE: Before gou begin, measure and mark depth
to ensure that adequate fiat countertop surface
is available.
For cooktop and downdraft combination depth:
, Follow cooktop installation instructions for cooktop
and downdraft combination installation.
• Otherwise, add 2-]/4" to the cooktop cutout depth.
NOTE: Add 2-7/8" to the cooktop cutout depth for
JP328 and JP626.
]/8" Minimum fiat counter-
top behind cutout required
*Required to maintain UL or CSAapprovals
Minimum*
