5) Test the voltage through the Power
Supply by inserting the prongs of the
voltmeter in the (2) copper plugs of the
Power Supply socket and turning the
unit to the ON position (28-32Vdc).
• If Power Supply is found to be defective, replace with a new Power Supply and perform another
Self Test.
• If Power Supply is found to be OK, proceed with the following steps.
RESULTS
