WiFly EXR QA12Bar IP
by pressing the SET UP button until "STRO.XX" is displayed. The
strobe can be adjusted between 00 (strobe off) to 15 (fastest
strobe).

Auto Run Mode:

In this mode the WiFly EXR QA12Bar IP will run a auto fade program.
1. Plug the fixture in and press the MODE button until "AUTO RUN
FADE:XX" is displayed. "XX" represents the fade speed.
2. Use the UP and DOWN buttons to adjust the fade speed. Adjust
the speed between "01" (fastest) and "99" (slowest) or "00" (Off).
3. After you have set your desired fade speed you can activate
strobing by pressing the SET UP button. "STRO.XX" will now be
displayed. The strobe can be adjusted between 00 (strobe off) to
15 (fastest strobe).

Static Color Mode:

1. Plug the fixture in and press the MODE button until "CLR MACS
COLOR: XX" is displayed. "XX" represents the current color num-
ber displayed (00-64).
2. There are 64 colors to choose from. Scroll through the 64 colors
using the UP and DOWN buttons. After you have found your de-
sired color you can activate strobing by pressing the SET UP but-
ton.
3. "STRO.XX" will be displayed. The strobe can be adjusted between
00 (strobe off) to 15 (fastest strobe).

Program Mode:

1. Plug the fixture in and press the MODE button until "PROGRAM
PRO:XX is displayed. "XX" represents a number from 1-22. Use
the UP or DOWN buttons to scroll through the 22 programs.
Programs 21 & 22 have adjustable colors. Once you have
found your desired program press the SET UP button.
2. Pressing the SET UP button will display "SPEED:XX". When this is
displayed you can adjust the running speed of your desired
program. Use the UP or DOWN button to adjust the speed
between "01" (slowest) and "99" (fastest). Once you have set your
desired running speed, you can press the SET UP button to enter
the fade adjustment mode.
3. Pressing the SET UP button will display "FADE:XX". When this is
ADJ Products, LLC - www.adj.com - WiFly EXR QA12Bar IP User Manual Page 10
Operating Instructions
WiFly EXR QA12Bar IP
displayed you can adjust the fade speed of your desired program.
Use the UP or DOWN button to adjust the speed between "01"
(fastest) and "99" (slowest) or "00" (Off).
4. Press the SET UP button again and "STRO:XX" will be displayed.
This is strobe adjustment, you can adjust the strobe speed of your
desired program using the UP or DOWN buttons. You can adjust
the speed between "01" (fastest) and "15" (slowest) or "00" (Off).
• PROGRAMS 21 & 22 - If you have chosen either programs 21 or
22, after the strobe adjustment, press the SET UP button.
"BACK:XX" will be displayed. This is the base or background
color, use the UP and DOWN buttons to scroll through the differnt
color settings. Once you have chosen your base color, press the
SET UP button again so that "COLO:XX" is displayed. This is the
moving color, use the UP and DOWN buttons to scroll through the
different colors.
DMX Mode:
Operating through a DMX controller gives the user the freedom to
create their own programs tailored to their own individual needs. This
function also allows you to use your fixtures as spot lights. The WiFly
EXR QA12Bar IP has 7 DMX modes: 4 Channel mode, 5 Channel
mode, 7 Channel mode, 9 Channel mode, 10 Channel mode, 12
Channel mode, and a 14 Channel mode. See pages 17-24 for each
mode's DMX traits.
1. This function will allow you to control each individual fixture's
traits with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
"DMX MODE ADDR:XXX" is displayed. "XXX" represents the dis-
played DMX address. Use the UP or DOWN buttons to scroll
through and find your desired DMX address.
3. After you have set your DMX address press the SET UP button so
that "CHAN:XX" is displayed. "XX" represents the current DMX
Channel mode that is displayed. Use the UP or DOWN buttons to
scroll through the DMX Channel modes.
4. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX control-
ler.
ADJ Products, LLC - www.adj.com - WiFly EXR QA12Bar IP User Manual Page 11
