ADJ WIFLY EXR QAI2BAR IP Instruction Manual page 5

WiFly EXR QA12Bar IP
on the other depending on model. Be sure to only use these cables for
intergrading this fixture in a standard DMX chain.
"First" Power Cable – A special power "First" cable is included with
every fixture. This cables is used to provide power to your fixture. This
cable comes with the IP rated twist lock connector on one end and a
standard Edison 3-prong, grounded prong on the other end. Be sure to
only use this cable for power distribution and never attempt to connect
this cable to the DMX lines.
You can chain multiple fixtures together through serial linking. Using REMOTE
INPUT OUTPUT
CONTROL
INPUT
the IP rated signal cables provided through ADJ. Always be sure to
daisy-chain your in and out data connections, never split or "Y" your
DMX connections unless you are using an approved DMX splitter such
as the ADJ WiFly D6 Branch or the original D6 Branch (Both not IP
rated).
POWER
Special Note: Line Termination.
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
Termination reduces signal errors and
avoids signal transmission problems
1 1
DMX512 IN
and interference. It is always advisable
3
3-PIN XLR
2 2 to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
5-Pin XLR DMX Connectors.
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
fixtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
3-Pin XLR to 5-Pin XLR Conversion
Conductor
Ground/Shield
Data Compliment (- signal)
Data True (+ signal)
Not Used
Not Used
ADJ Products, LLC - www.adj.com - WiFly EXR QA12Bar IP User Manual Page 8
REMOTE
INPUT OUTPUT
SOUND CONTROL
INPUT
When longer runs of cable are
Some manufactures use 5-pin DMX-
3-Pin XLR Female (Out) 5-Pin XLR Male (In)
Pin 1 Pin 1
Pin 2 Pin 2
Pin 3 Pin 3
Do Not Use
Do Not Use
Set Up WiFly EXR QA12Bar IP
LCD Display Lock:
The display will lock after 30 seconds. Press and hold the MODE
button for at least 10 seconds to unlock the display and access the
menu.
LED Display Backlight On/Off:
To set the LED display backlight to turn off after 30 seconds, press
the MODE button until "OTHER" is displayed. Press the SET UP but-
ton until BLGT:XXX" is displayed. "XXX" represents either ON or OFF.
Press the UP or DOWN buttons so that OFF is displayed. Now the
display light will turn off after 30s. Press any button to turn the dis-
play backlight on again.
Operating Modes:
The WiFly EXR QA12Bar IP has five operating modes:
• Static Color Mode - There are 64 colors to choose from.
POWER
• RGBA Mode - Choose one of the four colors to remain static or
adjust the intensity of each color to make your desired color.
• Auto Run - Will run a mixture of color fade and color change.
• Built-In Program mode - Select 1 of 22 built-in programs to run.
Program speed, fade, and strobing is adjustable.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller.
RGBA Dimmer Mode:
In this mode you can adjust RGBA colors to create your own color.
You can also use the color macro chart on page 23 to create one of
the 64 color macros.
1. Plug the fixture in and press the MODE button until "MANUAL" is
displayed. Use the SET UP button to scroll through RGBA colors.
2. When "RED:XXX" is displayed you are in Red dimming mode.
Use the UP and DOWN buttons to adjust intensity.
3. When "GREN:XXX" is displayed you are in Green dimming mode.
Use the UP and DOWN buttons to adjust intensity.
4. When "BLUE:XXX" is displayed you are in Blue dimming mode.
Use the UP and DOWN buttons to adjust intensity.
5. When "AMBE:XXX" is displayed you are in Amber dimming mode.
Use the UP and DOWN buttons to adjust intensity.
6. After you have set your desired color you can activate strobing
ADJ Products, LLC - www.adj.com - WiFly EXR QA12Bar IP User Manual Page 9
Operating Instructions
