FlashLogic FLRSCH5 Install Manual page 19

test moDuLe
I DURING PROGRAMMING
II DURING REMOTE START
III WITH IGNITION OFF
Automotive Data Solutions Inc. © 2013
moDuLe Diagnostics - 1 OF 1
Flashing RED Missing/wrong information from fi rmware or vehicle.
Solid RED Module waiting for more vehicle information.
Flashing GREEN Additional steps required to complete module programming.
Solid GREEN then OFF Module correctly programmed.
OFF No activity or module already programmed.
Flashing RED Module incorrectly programmed.
Solid RED Module incorrectly programmed.
Flashing GREEN Module correctly programmed and operational.
Solid GREEN then OFF Reset in progress.
OFF Invalid ground when running status from remote starter.
Flashing RED Module incorrectly programmed or connected.
Solid RED Module not programmed. Waiting for more vehicle information.
Flashing GREEN False ground when running status from remote starter.
Solid GREEN then OFF Reset in progress.
OFF Module at rest and ready for a remote start sequence.
OEM-CH(RS)-CH5-[FLRSCH5]-EN
Page 19 oF 21
• 20131125
DOC.: #13103
www.flashlogic.com
