FlashLogic FLRSCH5 Install Manual page 10

MODULE
G RF PORT/WEBLINK PORT
A
F TELEMATIC PORT
E
B
D
C
A
MS2 MS2
2 1
4 3
6 5
B
2 1
4 3
6 5
8 7
MS1 MS1
10 9
12 11
14 13
16 15
18 17
20 19
C
2 1 01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
4 3 02 GRAY - RAP SHUTDOWN (-) OUTPUT
6 5
8 7
10 9
12 11 11 GRAY/GREEN - HORN (-) OUTPUT
D
2 1
4 3
04 GRAY/WHITE - HOOD STATUS (-) INPUT
6 5
8 7
10 9 WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
Automotive Data Solutions Inc. © 2013
TYPE 2 - WIRING DIAGRAM - 1 OF 1
PURPLE (NC)
WHITE/YELLOW (NC)
WHITE/BROWN - PARKING LIGHT (MUX) OUTPUT
AFTERMARKET HOOD SWITCH (-)
OEM-CH(RS)-CH5-[FLRSCH5]-EN
VS2 VS2
VS1 VS1
PARKING LIGHT CONNECTION
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (MUX)
OR
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (-)
OR
87
85 86
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (+) 87A
30
OPTIONAL
Page 10 oF 21
• 20131125
DOC.: #13103
VEHICLE IGNITION SWITCH
A1
IGNITION CONNECTOR
A2
IGNITION HARNESS
A1
VEHICLE
PARKING LIGHT (MUX)
PARKING LIGHT (-)
10 AMPS
12V (+)
PARKING LIGHT (+)
DRIVER DOOR PIN (-)
HORN (-)
