OEM-CH(RS)-CH5-[FLRSCH5]-EN
notice
The manufacturer will accept no responsability for any electrical
damage resulting from improper installation of this product, be that either
damage to the vehicle itself or to the installed device. This device must be in-
stalled by a certified technician. Please review the Installation Guide carefully
before beginning any work.
Automotive Data Solutions Inc. © 2013
instaLL guiDe
Document numbeR
13103
Revision Date
20131125
FiRmwaRe
OEM-CH(RS)-CH5-[FLRSCH5]
haRDwaRe
FLRSCH5
accessoRies
FLPROG (REQUIRED)
beFoRe instaLLation
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
www.flashlogic.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLRSCH5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FlashLogic FLRSCH5

Summary of Contents for FlashLogic FLRSCH5

  • Page 1 OEM-CH(RS)-CH5-[FLRSCH5]-EN Document numbeR 13103 Revision Date 20131125 FiRmwaRe OEM-CH(RS)-CH5-[FLRSCH5] haRDwaRe FLRSCH5 accessoRies FLPROG (REQUIRED) notice beFoRe instaLLation The manufacturer will accept no responsability for any electrical damage resulting from improper installation of this product, be that either 1- Connect module to computer damage to the vehicle itself or to the installed device.
  • Page 2 • • • • • • • • • • 5500 chassis cab AT • • • • • • • • • • • • • * May require additional parts. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 3 12 PIN CONNECTOR G RF PORT/WEBLINK PORT TELEMATIC PORT AFTERMARKET HOOD SWITCH AND CABLE WARNING STICKER WEBLINK CABLE (required accessory sold separately) WEBLINK CABLE MODULE COMPUTER WEBLINK PORT USB PORT 4 PIN BLACK CABLE Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 4 Ignition switch Starter Black 5 pin Pink/Orange Ignition switch Parking Light* White/Purple Driver kick panel Grand Cherokee 05-07 Driver Door Pin Purple/Blue Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 5 CONNECT IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (+) WITHOUT OEM HOOD SWITCH: INSTALL AND CONNECT TO AFTERMARKET HOOD SWITCH PARKING LIGHT (+) DRIVER DOOR PIN (-) OPTIONAL HORN (-) AFTERMARKET HOOD SWITCH (-) Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 6 FAULTY CONNECTIONS AND PRODUCT MALFUNCTION STEP 3: STEP 3: -INSERT THE WIRE IN PIN 6 OF THE CONNECTOR, RIGHT NEXT TO WHERE IT USED TO BE. -INSULATE THE CONNECTIONS WITH ELECTRICAL TAPE. WHITE/RED WHITE/GREEN Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 7 Driver door module Hood Status Purple/LtBlue Switch Starter Parking Light* White/Purple + White/Green Driver kick panel Nitro 07-11 Driver Door Pin Purple Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 8 Purple/Blue Driver kick panel Hood Status Purple/Blue Switch Starter Parking Light* White/Purple Driver kick panel Liberty 08-12 Driver Door Pin Purple Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 9 Driver Door Pin Purple Driver kick panel Hood Status Purple/LtBlue Switch Starter 5500 Parking Light White/Green (MUX) Switch Driver Door Pin Purple Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 10 PARKING LIGHT (+) DRIVER DOOR PIN (-) 04 GRAY/WHITE - HOOD STATUS (-) INPUT OPTIONAL HORN (-) WITHOUT OEM HOOD SWITCH: INSTALL AND CONNECT TO AFTERMARKET HOOD SWITCH AFTERMARKET HOOD SWITCH (-) Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 11 Ignition switch Starter Black 5 pin Pink/Orange Ignition switch Parking Light* White/Purple Driver kick panel Grand Cherokee 05-07 Driver Door Pin Purple/Blue Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 12 CONNECT IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (+) WITHOUT OEM HOOD SWITCH: INSTALL AND CONNECT TO AFTERMARKET HOOD SWITCH PARKING LIGHT (+) DRIVER DOOR PIN (-) OPTIONAL HORN (-) AFTERMARKET HOOD SWITCH (-) Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 13 Turn key to ON position. Wait, LED will turn solid GREEN for 2 seconds. START LED will turn solid RED. Module Programming Procedure completed. Within 5 seconds, LED will fl ash GREEN rapidly. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 14 Turn key to OFF position then to ON position fi ve times [5x] rapidly. START Wait, LED 1 will turn solid RED for 2 seconds. Turn key to OFF position. START Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 15 Failure to exit the Module Navigation will drain button as many times as the menu number Navigation and redo the Module Navigation vehicle battery. indicates. LED 1 will fl ash GREEN an equal Procedure. amount of times continuously. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 16 35 MIN 15 min 02 sec 05 SEC 08 SEC 10 SEC WAIT TO START DELAY 15 SEC 20 SEC 25 SEC 30 SEC *Vehicle will shutdown when a door is opened. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 17 HORN EVENT TRIGGER LOCK + UNLOCK + START CONFIGURATION DOUBLE LOCK + START 30 msec HORN CHIRPS WIDTH 15 mSec 60 mSec 02-07 Technical Support only *Vehicle will shutdown when a door is opened. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 18 System is in Valet Mode. Vehicle is moving (VSS). Glow plug timeout error. RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence. CAN communication failure during RS sequence. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 19 Module not programmed. Waiting for more vehicle information. Flashing GREEN False ground when running status from remote starter. WITH IGNITION OFF Solid GREEN then OFF Reset in progress. Module at rest and ready for a remote start sequence. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 20 BLACK 20-PIN connector. DTC or a CHECK ENGINE error message. Wait, LED 1 will flash RED. RELEASE programming button. LED 1 will turn RED for 2 seconds. Module RESET completed. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
  • Page 21 Press unlock on OEM or aftermarket remote. Insert key into ignition. START Turn key to ON position. START Press and release BRAKE pedal. Take over procedure completed. Automotive Data Solutions Inc. © 2013 OEM-CH(RS)-CH5-[FLRSCH5]-EN www.flashlogic.com...
