Cable Requirements; Camera Description - Interlogix TruVision 11 Series Installation Manual

Cable requirements

For proper operation, adhere to the following cable and power
requirements for the cameras. Category 5 cabling or better is
recommended. All network cabling must be installed according
to applicable codes and regulations.

Camera description

Figure 1: IP wedge camera
2
10
3
5
4
7
1. Camera cover/housing
2. Lens
3. SD card
4. Ethernet RJ45 PoE port
5. Power supply
6. Base
Installation Guide
1
7.
8.
9.
10.
11.
6
Alarm and Audio port
Reset/WPS button
Converter pan
Antenna
Microphone
9
1 1
8
11
