Page 1: Ip Camera Installation
TruVision 12/32 Series IP Camera Installation Guide P/N 1072880-EN • REV C • ISS 02FEB15... - Page 2 © 2015 United Technologies Corporation, Copyright Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks patents or registered trademarks of the manufacturers or vendors of the respective products.
- Page 3 European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. Contact information For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu.
-
Page 5: Table Of Contents
Mounting the bullet camera 18 Mounting the VF dome camera 19 Mounting the outdoor dome camera 23 Using the camera with an Interlogix NVR or Hybrid DVR or another system 28 Using the camera with TruVision Navigator 28 Specifications 28... -
Page 6: Introduction
Introduction Product overview This is the installation guide for TruVision 12/32 Series IP camera models: TVC-1201 (1.3MPX IP box camera, PAL) TVC-3201 (1.3MPX IP box camera, NTSC) TVC-1202 (3MPX IP box camera, PAL) TVC-3202 (3MPX IP box camera, NTSC) ... -
Page 7: Installation
TVD-3203 (1.3MPX IP outdoor dome, 2.8-12mm, NTSC) TVD-1204 (3MPX IP outdoor dome, 2.8-12mm, PAL) TVD-3204 (3MPX IP outdoor dome, 2.8-12mm, NTSC) TVD-1205 (3MPX IP outdoor dome, 8-32mm, PAL) TVD-3205 (3MPX IP outdoor dome, 8-32mm, NTSC) Installation This section provides information on how to install the cameras. -
Page 8: Package Contents
immediately if the camera is wet and ask a qualified service person for servicing. Moisture can damage the camera and also create the danger of electric shock. Servicing: Do not attempt to service this camera • yourself. Any attempt to dismantle or remove the covers from this product will invalidate the warranty and may also result in serious injury. - Page 9 IP box camera • Camera • C-CS adaptor • CD with Configuration • Installation manual manual and TruVision Device Finder • WEEE and Battery Disposal Installation Guide...
-
Page 10: Installation Guide
IP VF bullet camera • Camera • Back box • Template • Alarm connector (2 pcs) Ceiling Mounting 1:Screw Hole for 2:Screw Hole for Bracket Mounting Base • Screws M4.8 × 18, 4pcs • Screws (4 pcs) to attach the back box Installation Guide... - Page 11 • Water joint: provide • Video cable water resistance to network connection. • CD with Configuration • Wrench manual and TruVision Device Finder • Installation manual • WEEE and Battery Disposal Installation Guide...
- Page 12 IP VF dome camera • Camera • Adaptor: for TVD-CB3 cup base • Template • 12 VDC Connector: DC jack socket to terminal connectors with positive and Drilling Templater negative indicators. • Water joint: provide • Screws (4 pcs) water resistance to network connection.
- Page 13 • Screws C: M4×8, 3pcs • Alarm connector (2 pcs) • Hex wrench • CD with Configuration manual and TruVision Device Finder • Installation manual • WEEE and Battery Disposal IP VF outdoor dome camera • Camera • Back box Installation Guide...
- Page 14 • Template (flush mount) • Template (back box) Drill Template Screws(4 pcs) Screws B (3 pcs) • • • Screws M4 × 9.5, 3pcs • Wrench to attach the back box • Alarm connector(4 pcs) • Water joint: provide water resistance to network connection.
-
Page 15: Cable Requirements
• Installation manual • CD with Configuration manual and TruVision Device Finder • WEEE and Battery Disposal CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE certified or LPS (limited power source) of the required output rating as listed on the unit. Cable requirements For proper operation, adhere to the following cable and power requirements for the cameras. -
Page 16: Camera Description
Table 1: Recommended power cable requirements Box camera: 12 VDC/24 VAC power wires or PoE (802.3af) VF bullet camera: 12 VDC power wires or PoE (802.3af) VF mini dome: 12 VDC power wires or PoE (802.3af) VF outdoor dome: 24 VAC power wires or PoE (802.3af) Camera description Figure 1: IP bullet camera Installation Guide... - Page 17 Ethernet RJ45 PoE port RS-232 serial port Power supply RS-485 port Reset button 10. Alarm In SD card 11. Audio Out BNC port 12. ABF (automatic back focus) button Ground 13. Audio In Alarm Out Note: To reset the camera to default settings, you need to press and hold the RESET button and power on the camera.
- Page 18 used when the auto-iris is driven by DC. Figure 2: IP VF bullet camera Shield Lens cover Mounting base BNC output Back box Alarm I/O Reset button Power supply SD card slot 10. Ethernet RJ45 PoE port Installation Guide...
- Page 19 Figure 3: IP VF dome camera Dome liner Adaptor Bubble Assembly Reset button Ethernet RJ45 RS485 Power cable 10. BNC cable Alarm cable 11. SD card slot Lens Installation Guide...
-
Page 20: Setting Up The Camera
Figure 4: IP VF outdoor dome camera Dome liner Ethernet RJ45 PoE port Bubble Assembly Power supply SD card Lens Analog video output Alarm I/O Reset button Setting up the camera Note: If the light source where the camera is installed experiences rapid, wide- variations in lighting, the camera may not operate as intended. -
Page 21: Ir Illuminators
To quickly put the camera into operation: Prepare the mounting surface. Mount the camera on the mounting surface using the appropriate fasteners. See “Mounting the bullet camera” on page 18. Set up the camera’s network and streaming parameters so that the camera can be controlled over the network. For further information, please refer to the “TruVision 12/32 series IP Camera Configuration Manual”. -
Page 22: Accessing The Sd Card
Accessing the SD card Insert a Micro SD card with up to 64GB for local storage as a backup in case, for example, the network fails (see Figure 1 on page 12). The card is not supplied with the camera. For the IP VF mini dome and outdoor dome cameras, point the lens vertically upwards to access the SD card slot. -
Page 23: Mounting The Vf Dome Camera
Hook the camera to the back box with the safety cable. Use the screws to fix the camera to the back box. Mounting the VF dome camera To mount the VF dome camera on a ceiling or wall: Loosen the three screws on the edge of the lower dome with a wrench. - Page 24 Screws Open the lower dome and remove the black inner liner. Using the drill template, drill three holes in the mounting surface. Installation Guide...
- Page 25 Screw holes Cable holes If you want to route the cables behind the dome, drill a cable hole in the ceiling or wall using the drill template. Mount the camera to the ceiling or wall by aligning the housing holes with those in the ceiling. Secure the camera with the supplied screws as shown below.
- Page 26 Route the cables through the side hole of the dome by removing the cover. Connect the video output connector to the monitor. Connect the power connector to the power supply. View the camera image using the monitor. Adjust the pan, tilt and azimuth angle. Loosen and adjust the zoom and focus lever to obtain the appropriate angle of view and optimum focus.
-
Page 27: Mounting The Outdoor Dome Camera
Mounting the outdoor dome camera To mount the outdoor dome camera on a ceiling: Drill the screw holes on the ceiling with the supplied drilling template. To route the cables from the base of the camera, cut a cable hole in the ceiling. Ceiling Mounting 1:Screw Hole for 2:Screw Hole for... - Page 28 Install the dome camera to the mounting base. Adjust the surveillance angle. 1) Loosen the lock screw besides the lens. Installation Guide...
- Page 29 2) Hold the plastic plate and rotate the camera to adjust the panning angle [0~350°]. 3) Push the lens forward and backward to adjust the tilting angle [0~80°]. 4) Rotate the lens to adjust the azimuth angle of the camera [0~350°]. 5) Tighten the lock screw.
- Page 30 To mount the outdoor dome camera into a ceiling: Drill the screw holes on the ceiling with the supplied drilling template. Drill Template Remove the housing and liner from the camera. Install the camera to the hole with three screw, Installation Guide...
- Page 31 Re-attach the housing and liner. Installation Guide...
-
Page 32: Using The Camera With An Interlogix Nvr Or Hybrid Dvr Or Another System
Using the camera with TruVision Navigator A camera must be connected to an Interlogix NVR or hybrid DVR in order to be operated by TruVision Navigator. Please refer to the TruVision Navigator user manual for instructions on operating the camera with the TruVision Navigator. -
Page 33: Truvision Ip Vf Mini Dome
69.8 × 58 × 145 mm Dimensions (2.68” x 2.56” x 5.70 in.) Weight 830g (1.83 lbs.) TruVision IP VF mini dome Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption 1.3MPX: Max. 6 W (max. 8 W with IR on) 3MPX: Max. -
Page 34: Truvision Ip Vf Bullet Cameras
TruVision IP VF bullet cameras Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption 1.3MPX: Max. 12 W 3MPX: Max. 12.5 W Miscellaneous Connectors DC power: screw terminal RJ45: female connector Alarm: screw terminal Operating temperature -30 to +60 °C (-22 to 140°F) -40°C to +60°C (-40°F to +140°F) , with heater on 98 x 105 ×... -
Page 35: Pin Definitions
Operating temperature -30 to +60°C (-22 to +140°F) -40 to +60°C (-40 to +140°F), with heater on Φ 159.8 × 146 mm Dimensions (Φ 6.29” × 5.75”in.) Weight 2100 g (4.62 lbs.) Environmental rating IP66, IK10 Pin definitions There are eight wires on a standard UTP/STP cable and each wire is color-coded. - Page 36 Figure 6: Cross-over cable White/Orange White/Orange Orange Orange White-Green White-Green Blue Blue White/Blue White/Blue Green Green White/Brown White/Brown Brown Brown Please make sure your connected cables have the same pin assignment and color as above before deploying the cables in your network.
