Cordless Driver Drill
Equipped with Electric Brake
MODEL 6019D
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
w w w . m a k i t a t o o l s . c o m

Advertisement

Table of Contents
loading

Related Manuals for Makita MODEL 6019D

Summary of Contents for Makita MODEL 6019D

  • Page 1 Cordless Driver Drill Equipped with Electric Brake MODEL 6019D I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Model Capacities No load speed (RPM) Overall length Net weight Battery Cartridge 7000 Voltage 7.2 V A. C. only 50 Hz - 60 Hz • Manufacturer reserves the right to change specifications without notice. • Specifications may differ from country to country. GENERAL SAFETY RULES (FOR All BATTERY OPERATED TOOLS) WARNING:...
  • Page 3 3. Keep bystanders, children, and visitors away while operating a power tool. Distrac- tions can cause you to lose control. Electrical Safety 4. A battery operated tool with integral bat- teries or a separate battery pack must be recharged only with the specified charger for the battery.

  • Page 4: Specific Safety Rules

    6. Keep hands away from rotating parts. 7. Do not leave the tool running. Operate the tool only when hand-held. 8. Do not touch the drill bit or the workpiece immediately after operation; they may be extremely hot and could burn your skin.
  • Page 5 (1) battery charger, (2) battery, and (3) product using battery. 3. CAUTION - To reduce risk of injury, charge only MAKITA rechargeable marked on the charger label. Other types of batteries may burst causing personal injury and damage.
  • Page 6 when service or repair is required, Incor- rect reassembly may result in a risk of electric shock or fire. 12. To reduce risk of electric shock, unplug charger from outlet before attempting any maintenance or cleaning. Turning off con- trols will not reduce this risk. 13.

  • Page 7: Functional Description

    5. After charging, unplug the charger from the power source. NOTE: • The battery charger is for charging Makita battery cartridge. Never use it for other purposes or for other manufacturer’s batteries.

  • Page 8: Switch Action

    002863 1. Switch trigger • If you try to charge a battery cartridge from a just operated tool, sometimes the charging light will not come on. If this occurs, let the cartridge cool off for a while. Then re-insert it and try to charge it once more. •...

  • Page 9: Electric Brake

    This tool is equipped with an electric brake. If the tool consis- tently fails to quickly stop after switch trigger release, have tool serviced at a Makita service center. Reversing switch action This tool has a reversing switch to change the direction of rotation.

  • Page 10: Adjusting The Fastening Torque

    Installing or removing driver bit or drill bit Hold the ring and turn the sleeve counterclockwise to open the chuck jaws. Place the bit in the chuck as far as it will go.
  • Page 11 Place the point of the driver bit in the screw head and apply pressure to the tool. Start the tool slowly and then increase the speed gradually. Release the switch trigger as soon as the clutch cuts in. NOTE: • Make sure that the driver bit is inserted straight in the screw head, or the screw and/or bit may be damaged.

  • Page 12: Maintenance

    Makita Authorized or Factory Service Centers, always using Makita replacement parts. Recycling the Battery The only way to dispose of a Makita battery is to recycle it. The law prohibits any other method of disposal. To recycle the battery: 1. Remove the battery from the tool.
  • Page 13 CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 14 Memo...
  • Page 15 Memo...
  • Page 16 Memo...
  • Page 17 First-Class Postage Required Post Office will not deliver without proper postage. Makita U.S.A., Inc. 14930 Northam Street La Mirada, CA 90638-5753 Fold...
  • Page 18 Paste 3. How did you learn about this product: Magazine From Dealer Newspaper Store Display Catalog 4. Most favored points are: Design Features Size Price Makita Brand MODEL NO. YEAR SERIAL NO. PHONE 20-29 30-39 40-49 Paste Paste Radio Exhibition...

  • Page 19: Factory Service Centers

    Date Purchased When you need service: Send complete tool (prepaid) to one Dealer’s Name & Address of the Makita Factory Service Centers listed, or to an Authorized Makita Service Center. Be sure to attach a letter to the outside of Model No.

  • Page 20: Warranty Policy

    MAKITA LIMITED ONE YEAR WARRANTY Warranty Policy Every Makita tool is thoroughly inspected and tested before leaving the factory. It is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase.
