16-Port Gigabit Web Smart Switch
This Web Smart switch provides sixteen
10-/100-/1000-Mbps ports.
Supports Gigabit speed on all ports.
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
Customer
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax
Support
724-746-0746 • www.blackbox.com • info@blackbox.com
Information
LGT616A
LGT616A-JP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LGT616A-JP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Black Box LGT616A-JP

  • Page 1 LGT616A LGT616A-JP 16-Port Gigabit Web Smart Switch This Web Smart switch provides sixteen 10-/100-/1000-Mbps ports. Supports Gigabit speed on all ports. Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) Customer FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax Support 724-746-0746 •...
  • Page 2 FCC and IC RFI Statements FEDERAL COMMUNICATIONS COMMISSION and INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS Class B Digital Device. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 NOM Statement Normas Oficiales Mexicanas (NOM) Electrical Safety Statement INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
  • Page 4 NOM Statement 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada. 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
  • Page 5 Disclaimer Black Box Network Services shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Network Services may revise this document at any time without notice.
  • Page 6: Table Of Contents

    Table of Contents Table of Contents Specifications .................... 8 Overview ....................9 Introduction .................. 9 Features ..................9 What’s Included ................. 10 Hardware Description ..............10 Configuration ...................12 Configuration: System Configuration ..........13 Configuration: Port Configuration ..........14 Configuration: VLAN Configuration ..........15 Configuration: Aggregation/Trunk Configuration ......15 Configuration: IGMP Configuration...
  • Page 7 Chapter 1: Specifications 1. Specifications Buffer Memory 512 KB Compliance CE, FCC Class A Filtering/Forwarding Rate 1000-Mbps port: 1,488,000 pps; 100-Mbps port: 148,800 pps; 10-Mbps port: 14,880 pps Jumbo Frames 9.6 KB MAC Address Smart Features • Number of Ports: 16 x 10/100/1000M RJ-45 Port on the Rear •...
  • Page 8: Specifications

    Chapter 1: Specifications Transmission Media 10BASE-T CAT3, 4, 5 UTP/STP; 100BASE-TX CAT5 UTP/STP; 1000BASE-T CAT 5E UTP/STP Connectors (16) RJ-45, (1) power connector Indicators Per Port LEDs: 10/100M Link/Act; 1000M Link/Act (Green On/Quick Blinking); System: On— Power On (Amber) Power Internal power supply: Input Voltage: 100–240 VAC, 50-60 Hz;...
  • Page 9: Overview

    Chapter 2: Overview 2. Overview 2.1 Introduction The 16-Port Gigabit Web Smart Switch provides sixteen 10-/100-/1000-Mbps ports. It is designed for easy installation and enables high performance in an environment where traffic on the network and the number of users increase continuously.
  • Page 10: What's Included

    • Smart plug and play. 2.3 What’s Included Your package should contain the following items. If anything is missing or damaged, contact Black Box Technical Support at 724-746-5500 or info@blackbox.com. • (1) 16-Port Gigabit Web Smart Switch • (1) U.S. power cord •...
  • Page 11 Chapter 2: Overview Table 2-1. 16-Port Web Smart Gigabit Ethernet Switch components. Number Component Description (1) Reset button Press to Reset the switch to its factory defaults. (1) Power LED Lights when power to the unit is on. (16) 1000M LEDs Light when a port is operating at 1000 Mbps.
  • Page 12: Configuration

    Chapter 3: Configuration 3. Configuration Follow these steps to configure the Web Smart switch. Step 1: Use a twisted-pair cable to connect this switch to your PC. Step 2: Set your PC’s IP to 192.168.2.xx. Figure 3-1. IP screen. Step 3: Open a Web browser (for example, Internet Explorer …) and go to ®...
  • Page 13: Configuration: System Configuration

    Chapter 3: Configuration Step 4: On the home page, select the configuration by clicking the icon: - Configuration - Monitoring - Maintenance - Logout 3.1 Configuration: System Configuration Figure 3-3. System Configuration screen. This will show system status, such as: MAC address, system firmware version, and other system information.
  • Page 14: Configuration: Port Configuration

    Chapter 3: Configuration You can change the user name, the password, and IP address, then click “Apply” to confirm the new change. Next, you must reset the switch by turning it off and turning it on to take the new user name, the password, and IP address.
  • Page 15: Configuration: Vlan Configuration

    Chapter 3: Configuration 3.3 Configuration: VLAN Configuration Figure 3-5. VLAN Configuration screen. There are 16 VLAN groups. Select and add a group into “VLAN ID” and then click the port number that you want to put into the selected VLAN group. 3.4 Configuration: Aggregation/Trunk Configuration Figure 3-6.
  • Page 16: Configuration: Igmp Configuration

    Chapter 3: Configuration Set up port trunk groups and then click the port number you want to include into the same group. There are eight groups to choose from, and the maximum number of ports for one group is 16. 3.5 Configuration: IGMP Configuration Figure 3-7.
  • Page 17: Configuration: Port Mirror Configuration

    Chapter 3: Configuration 3.6 Configuration: Port Mirror Configuration Figure 3-8. Port Mirror Configuration screen. Port mirroring is used to mirror the traffic from the source port to the destination port. Select the destination port from Port 1 to Port 16, and then select the source port by clicking the port’s checkbox.
  • Page 18: Configuration: Lldp Configuration

    Chapter 3: Configuration 3.7 Configuration: LLDP Figure 3-9. LLDP Configuration screen. 3.8 Configuration: QoS Configuration Figure 3-10. QoS Configuration screen. You can enable or disable QoS by clicking the checkbox. If you enable QoS, you can select the class of service for each port. LGT616A Page 18 724-746-5500 | blackbox.com...
  • Page 19: Monitoring

    Chapter 4: Monitoring 4. Monitoring 4.1 Monitoring: Statistics Overview for All Ports Figure 4-1 Statistics Overview for All Ports screen. You can read statistics for all ports. 4.2 Monitoring: Detailed Statistics Figure 4-2. Detailed Statistics screen. For detailed statistics for each port, click the port number. LGT616A Page 19 724-746-5500 | blackbox.com...
  • Page 20: Monitoring: Igmp Status

    Chapter 4: Monitoring 4.3 Monitoring: IGMP Status Figure 4-3. IGMP Status screen. You can read IGMP status for IGMP ports. 4.4 Monitoring: LLDP Status Figure 4-4. LLDP Status screen. You can read LLDP status for LACP ports. LGT616A Page 20 724-746-5500 | blackbox.com...
  • Page 21: Monitoring: Lldp Table

    Chapter 4: Monitoring 4.5 Monitoring: LLDP Table Figure 4-5. LLDP Table screen. You can view the LLDP table in this screen. 4.6 Monitoring: Ping Parameters Figure 4-6. Ping Parameters screen. You can set a target IP address in the Ping Parameters screen. LGT616A Page 21 724-746-5500 | blackbox.com...
  • Page 22: Maintenance

    Chapter 5: Maintenance 5. Maintenance 5.1 Maintenance: Warm Restart Figure 5-1. Warm Restart screen. To restart while keeping the switch power on, select “yes” in this screen. 5.2 Maintenance: Factory Default Figure 5-2. Factory Default screen. To reset the switch to its factory default settings, click “yes” in this screen. LGT616A Page 22 724-746-5500 | blackbox.com...
  • Page 23: Maintenance: Software Upload

    Chapter 5: Maintenance 5.3 Maintenance: Software Upload Figure 5-3. Software Upload screen. Follow the instructions on this screen to upload the new software. 5.4 Maintenance: Configuration Upload Figure 4-1.Configuraition Upload screen. Follow the instructions on this screen to upload or download the new configuration.
  • Page 24: Reset Button

    Chapter 6: Reset Button 6. Reset Button If you forgot your IP or password, use the Reset button to reset the switch to factory defaults. Follow these steps: Step 1: Turn on the Web Smart Switch. Step 2: Press and hold the reset button continuously for 15 seconds and release the reset button.
  • Page 25 NOTES LGT616A Page 25 724-746-5500 | blackbox.com...
  • Page 26 NOTES LGT616A Page 26 724-746-5500 | blackbox.com...
  • Page 27 NOTES LGT616A Page 27 724-746-5500 | blackbox.com...
  • Page 28 724-746-5500 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 60 seconds or less.
