- Page 1 OFNA Racing 22692 Granite Way, Ste. B Laguna Hills, Ca. 92653 (949) 586-2910 Www.ofna.com RTR Instruction Manual PURE COMPETITION... PRE-ASSEMBLED ASSEMBLED CHASSIS WITH RADIO AND ENGINE...
- Page 2 REQUIRED FOR OPERATION You will need to buy a few items to start the engine and run the car. THINGS NEEDED • Use 20% nitro CAR fuel. Do not use airplane fuels, they will over heat engine. • Buy long glow plugs, like OFNA/PICCO P-7 (#51007). Use plugs without idle bar.
- Page 3 READ THIS BEFORE RUNNING Running a nitro kit is fun and easy, but to make this a safe • Clear oil and dirt from chassis with a degreaser. and good experience you must observe a few rules. This Precautions kit is extremely fast, easily over 40MPH, and can seriously •...
- Page 4 * Align throttle servo same CHECKING ENGINE THROTTLE as shown. Brake © 1. Insert AA batteries into 1. Push trigger to full 1. Pull Full Throttle. transmitter (8 Pcs). brake position. 2. Adjust alum. Stopper to 2.Turn on transmitter. increase or decrease 3.Turn on receiver.
- Page 5 ASSEMBLY OF THE CLUTCH INTO ENGINE Notes: Non-Pull Start Engines... 3 x 5mm Screw • Alum. Washer behind the flywheel is not needed when using Force engines or similar types. O.S. Engines will require washer spacer. • To check!..place the brass corn #10330 (big hole) against the engine bearing, then flywheel. You should be 3 X 8mm covering one or two thread of the engine shaft.
- Page 6 ASSEMBLY OF THE BRAKE SYSTEM 2x8mm Screw 2x4mm #30800 Screw 3x12mm Brake System Plastic Parts Set Screw 2x6mm Washer Slider Servo Mount 2x25mm 3X3mm Screw Set Screw Tie-Rod End 2x6mm 2mm Nut Washer Tie-Rod End A-80B Adjust 2x4mm Mount Adjust Nut Screw ALIGN THROTTLE SERVO AND BRAKE SAME AS SHOWN ( Neutral Position )
-
Page 7: Starting Of The Engine
ASSEMBLY OF THE TIRES, FOAM INSERTS AND WHEELS #86044 - Red #86091 #86045 - White Mini XX- Pin Tire #86046 - Lime #86047 - Yellow 17mm 5-Star Wheels Front Knuckle Arm Assembly #15071 17mm Wheel Nuts Always use tire foam donut when building tires. - Page 8 ENGINE BREAK-IN AND TUNNING (BREAK-IN THE ENGINE BEFORE DRIVING THE CAR!) • Choose a wide clear outdoor location with low dirt and dust. OPTIONAL OFNA CAR STANDS • Set the car on box or holder with wheels off the ground. •...
- Page 9 1:1 SCREW SHEET 3 x 5mm Cap Screw 3 x 3mm Set Screw M3 Nut 3 x 5mm Set Screw 3 x 10mm Cap Screw M4 Nut 3 x 8mm Set Screw 3 x 12mm Cap Screw 3 x 10mm Set Screw M3 Nylon Locknut 3 x 15mm Cap Screw 3 x 15mm Set Screw...
