Summary of Contents for Briteq BTX 300 Beam

  • Page 2 DANGER ~ GEVAAR ~ GEFAHR ~ PELIGRO ~ PERIGO WARNING: DANGER! never expose the lens to direct sunlight, even for a short period. This may damage the light effect or even cause fire! ATTENTION: DANGER! n'exposez jamais la lentille directement aux rayons de soleil, même pendant un bref instant.

  • Page 3: Safety Instruction

    In the event of serious operating problem, stop using the unit immediately.   Never turn on and off the unit time after time. The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly  damaged. Fig.1 Fig.2 BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...

  • Page 4: Technical Specification

    - Blackout, 0~100% smooth dimming, independent shutter and various strobe effect. Color wheel - Color wheel: 7 dichroic colors + open. - Rainbow effect in both directions. - Easy calibration and maintenance by magnetic home positioning. BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...
  • Page 5 5.Tilt unlock button (Gray) ,7 Power Cable: 6.Pan lock To connect to the mains supply 7.Handle ○ ,8 Fuse (T 10 A): 8.Base Protect the unit from damage of overcurrent. 9.Antenna (for XP-300A BEAM WT only) BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...

  • Page 6: Gobo And Lamp

    5. Tighten the screws (A) to fix the lamp cover. 6. Turn the screws (B) to adjust the lamp position be sure it is located in the center of the reflector for the best projection. BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...
  • Page 7 In the event of disconnecting with mains power, press UP button for one minute to enter into menu mode. Press MENU button or let the unit idle one minute to exit. The main functions are shown below（the grayed boxes are preset settings）: BRITEQ® BTX-300BEAM BRITEQ®...

  • Page 8: Dmx Functions

    UP and DOWN button to view other DMX value. back to the last menu or let the unit idle one minute to exit menu mode. Press MENU button back to the last menu or let the unit idle one minute to exit menu mode. BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...

  • Page 9: Lamp Setting

    UP and DOWN button to select Yes (Lamp turns on when DMX signal is Backlight Intensity detected) or No (keep the present state), press ENTER button to store. Press MENU Select Backlight Intensity, press ENTER button to confirm, present mode will blink on BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...

  • Page 10: Fixture Information

    Interval Select Interval, press ENTER button to confirm, the interval time will show on Reset Functions the display. Press MENU button to exit. Enter menu mode, select Reset Function, press ENTER button to confirm, use UP BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...
  • Page 11 UP and DOWN button to offset the value from 0 to 255, press ENTER button to store. Press MENU button to exit. Shutter — Shutter home position adjust Enter offset mode, Select Shutter, press ENTER button to confirm, the present position will BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...

  • Page 12: Control By Universal Dmx Controller

    3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+) 5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin4, Pin5 not used. BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...
  • Page 13 1. The unit will maintain the last condition until reset if you cut-off the DMX signal. 2. For the channel Function, keep the value for about 5 seconds, then the corresponding function will take into effect. BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...
  • Page 14 18 Channels mode 2: BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...
  • Page 15 25 Channels mode: BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...

  • Page 16: Troubleshooting

    5. Change a new belt (D), put the belt around the axis gear and motor gear. 6. Plug all the connect wires back upon the belt. 7. Tighten all the screws. F. If The tilt belt is broken 1. Turn off the mains power. BRITEQ® BTX-300BEAM BRITEQ® BTX-300BEAM...
