WiFly EXR HEX5 IP
Operating Power:
There are two ways to supply power to this unit; battery power or AC
power.
• AC Power - To run the unit using AC power, plug the unit into a
power source, and put the Load Switch into the ON position. When
using AC power make sure the Battery Switch is in the OFF position.
• Battery Power - To run the unit using Battery power, press the bat-
tery button located on the bottom of the fixture across from power
input connection. Follow the instructions on page 15 to activate the
battery load.
LCD Display Lock:
The display will lock after 30 seconds. Press and hold the MODE
button for at least 10 seconds to unlock the display and access the
menu.
Energy Saving Mode
This will decrease the LED's brightness gradually when the battery
life is less than 80%, this is will extend the battery life.
1. To activate energy saving mode, press the MODE button until
"Energy SAVE:XX" is displayed. "XX" represents either "ON" or
"OFF".
2. Press the UP or DOWN button so that "ON" is displayed. If "ON"
is displayed already then the fixture is already in energy saving
mode.
LED Display On/Off:
To set the LED display light to turn off after 20 seconds, press the
MODE button until "OPTION" is displayed. Press the SET UP button
so that BLGT:XXX" is displayed. "XXX" represents either ON or OFF.
Press the UP or DOWN buttons so that OFF is displayed. Now the
display light will turn off after 30s. Press any button to turn the dis-
play on again.
Operating Modes:
The WiFly EXR HEX5 IP has five operating modes:
• Static Color Mode - There are 63 colors to choose from.
• RGBWA+UV Dimmer Mode - Choose one of the six colors to
remain static or adjust the intensity of each color to make your
ADJ Products, LLC - www.adj.com - WiFly EXR HEX5 IP User Manual Page 12
Operating Instructions WiFly EXR HEX5 IP
desired color.
• Auto Run - Will run a mixture of color fade and color change.
• Color Change Mode - Select 1 of 16 color change programs to run.
Color change speed is adjustable.
• Color Fade Mode - Select 1 of 16 color fade programs to run.
Color fade speed is adjustable.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller.
RGBWA+UV Dimmer Mode:
1. Plug the fixture in and press the MODE button until "MANUAL" is
displayed. Then press the SET UP button to scroll through
RGBWA & UV colors.
2. When "RED:XXX" is displayed you are in Red dimming mode.
Press the UP and DOWN buttons to adjust intensity.
3. When "GREN:XXX" is displayed you are in Green dimming
mode. Press the UP and DOWN buttons to adjust intensity.
4. When "BLUE:XXX" is displayed you are in Blue dimming mode.
Press the UP and DOWN buttons to adjust intensity.
5. When "WHIE:XXX" is displayed you are in White dimming mode.
Press the UP and DOWN buttons to adjust intensity.
6. When "AMBR:XXX" is displayed you are in Amber dimming mode.
Press the UP and DOWN buttons to adjust intensity.
7. When "UV:XXX" is displayed you are in UV dimming mode. Press
the UP and DOWN buttons to adjust intensity.
8. After you have adjusted the RGBWA & UV colors to make your
desired color you can then activate strobing by pressing the SET
UP button to enter the strobe mode.
9. "STROB.XX" will be displayed, this is strobe mode. The Flash can
be adjusted between 00 (flash off) to 15 (fastest flash).
Color Change Mode:
1. Plug the fixture in and press the MODE button until "JUMP RUN
SNAP:XX" is displayed. "XX" represents a number between 01-16.
2. Use the UP and DOWN buttons to find your desired color change
mode.
3. Press the SET UP button and "SPEED:XX" will be displayed. Use
the UP and DOWN buttons to adjust the speed of the color
change.
ADJ Products, LLC - www.adj.com - WiFly EXR HEX5 IP User Manual Page 13
