ADJ WiFLY EXR HEX5 IP User Instructions page 11

WiFly EXR HEX5 IP
The ADJ RFC remote (sold seperately) has many different functions and al-
lows you to control your WiFly EXR HEX5 IP from long distance. The ADJ
RFC remote can control your system up to 150 ft. To use the RFC you must
first activate the fixtures receiver, to activate the receiver please see the in-
structions on page 16.
BLACKOUT - Pressing this button will blackout the fixture. Press this button
for more then 3 seconds to return to default settings.
AUTO RUN - Pressing this button will cycle through auto run, color change
mode, and color fade mode. In the color change and color fade modes
you can use the "+" and "-" buttons to find scroll through the 16 different
programs. You can control the speed of each of the modes by pressing the
SPEED button and using the "+" and "-" buttons.
PROGRAM SELECTION - Pressing this button will switch between static
color mode and slave mode. Use the "+" or "-" to scroll through the 63 static
colors. Once you have found your color, you can press the FLASH button to
activate strobing and use the "+" or "-" to adjust the flash rate.
FLASH - This button will activate the flash (strobe) effect. You can control
the flash speed using the "+" and "-" buttons.
SPEED - Press this button and use the "+" & "-" buttons to adjust the speed
in Program mode.
SOUND ACTIVE - This button is not used with fixture.
R G B W/A - Press either one of these buttons and use the "+" or "-" to ad-
just the brightness. Press the FLASH button to activate strobing and use
the "+" or "-" buttons to adjust the Flash rate. Note: Use the W/A button to
choose white, amber, & UV. Each press of this button will change to the next
color.
"+" and "-" - Use these buttons to adjust the flash rate, select your desired
program, adjust the color change speed, color fade speed, auto run speed,
RGBWA & UV brightness, and to scroll through the Static colors.
ADJ Products, LLC - www.adj.com - WiFly EXR HEX5 IP User Manual Page 20
ADJ RFC Operation WiFly EXR HEX5 IP
Channel Value
1
0 - 255
2
0 - 255
3
0 - 255
4
0 - 255
5
0 - 255
6
0 - 255
WiFly EXR HEX5 IP
Channel Value
1
0 - 255
2
0 - 255
3
0 - 255
4
0 - 255
5
0 - 255
6
0 - 255
7
0 - 255
ADJ Products, LLC - www.adj.com - WiFly EXR HEX5 IP User Manual Page 21
6 Channel Mode
Function
RED
0% - 100%
GREEN
0% - 100%
BLUE
0% - 100%
WHITE
0% - 100%
AMBER
0% - 100%
UV
0% - 100%
7 Channel Mode
Function
RED
0% - 100%
GREEN
0% - 100%
BLUE
0% - 100%
WHITE
0% - 100%
AMBER
0% - 100%
UV
0% - 100%
MASTER DIMMER
0% - 100%
