GENERAL SYSTEM CONFIGURATIONS
The following is intended to provide some of the system configurations that are possible with the ADVDLX9 Overhead LED Backlit LCD Monitor
with DVD Player:
The ADVDLX9 has an option that allows the user to select from two IR transmit and receive codes (M1 or M2). This feature can be used when using
two ADVDLX9s in the same installation or if the vehicle has an RSA (Rear Seat Audio) that uses an "A" channel headset. The ADVDLX9 comes factory
set to M1. When in the M1 mode the unit will respond to remote commands when M1 is selected on the remote and will transmit audio on the A
channel. When in the M2 mode the unit will respond to remote commands when M2 is selected on the remote and will transmit audio on the B
channel.
NOTE: M1 will appear on the screen for 4~5 seconds.
Selecting a Monitor Code (M1 or M2)
1. Power ON the unit and wait until M1 on the OSD appears. M1 will appear on the screen for 4~5 seconds.
2. To change the monitor code, press the System Menu button.
3. Use the cursor buttons to select the Monitor Mode menu option. Press OK to confirm the setting.
p or q
4. Use the p or q cursor buttons to select the desired monitor mode (M1 or M2), then press OK to confirm the setting.
5. Press the System Menu button on the remote to exit the System Menu mode.
The two overheads can be connected together using the RCA cables.
• Plug the AV OUT of the M1 unit into the AV IN of the M2.
• Plug the AV IN of the M1 unit into the AV OUT of the M2.
FMM 88.3MHz AUX/GAME
M1
IRT ON
SYSTEM MENU
FM MODULATOR
OSD LANGUAGE
DEFAULT DVD ON/OFF
SCREEN MODE
MONITOR MODE
3
FMM OFF DVD
M2
IRT OFF
WARNING
SETTING THE MONITOR TO THE M2 MODE WILL
REQUIRE USING 2-CHANNEL HEADPHONES.
USE THE DOWN KEY ON THE REMOTE CONTROL
TO SELECT M2 AND PRESS OK TO SET THE
MONITOR TO M2 MODE
TO REMAIN IN THE M1 MODE PRESS OK
M1
M2
