INSTALLING THE SCREW CAPS AND USB COVER

Installing the Screw Caps
1. After the unit is mounted to the headliner, install the two snap in Screw Caps. The snap in Screw Caps are marked "L" and "R" on the
inside.
a. Facing the front of the vehicle, press the snap in Screw Cap marked "L" into the left screw hole.
b. Facing the front of the vehicle, press the snap in Screw Cap marked "R" into the right screw hole.
Installing the USB Cover
1. Install the USB Cover by feeding the Cover tether into the opening located below the USB connector.
Snap-in
Two
Screw
Caps
16
USB
Cover
Snap-in
