Technical Specifications

Standard:
IEEE802.11ac/a/n on 5 GHz
IEEE802.11b/g/n on 2.4 GHz
IEEE802.3at
Antenna
6 External N-type Antennas
3 x detachable 5 dBi 2.4 GHz omni-directional antennas
3 x detachable 7 dBi 5 GHz omni-directional antennas
Physical Interface
2 x 10/100/1000 Gigabit Ethernet Port with PoE support
LAN1 Port: IEEE 802.3at PoE Input
LAN2 Port: IEEE 802.3af PoE Output
Both Ethernet Ports support Surge Protection to 6KV
LED Indicator
Power
LAN 1
LAN 2
2.4 GHz
5 GHz
Power Requirements
External Power Adapter, DC IN, 48V/0.8A
IEEE 802.3at support
Operation Modes
Access Point
WDS
Mesh
WDS Detail
WDS AP
WDS Bridge
WDS Station
Mesh Detail
Mesh AP
Mesh Only (2.4 GHz)
Management
Auto Channel Selection
Multiple SSID: 16 SSIDs, 8 SSIDs per Radio
BSSID
SNMP V1/V2c/V3
MIB I/II, Private MIB
VLAN Tag/VLAN Pass-through
Clients Statistics
Save Configuration as User Default
Fast Roaming
E-Mail Alert
RADIUS Accounting
Guest Network
Band Steering
Fast Handover
MIB
I/II
Private MIB
Spanning Tree Protocol
Supports 802.1d Spanning Tree Protocol
8
