CONTROL PANEL BUTTON LOCATIONS

1 12 2 13
14
1. POWER/SRC (source) button
2. SEL (select/menu) button and VOL (volume) knob
3. BAND button and
4. AMS (automatic music search) button
5. >|| or 1 button
6.
INT (intro) or 2 button
7.
RPT (repeat) or 3 button
8.
RDM (random) or 4 button
9.
-10 or 5 button
10.
+10 or 6 button
11.
CLK (clock) button and
12.
|<< button
13.
>>| button
14.
MUTE button
15.
EJECT button
16.
RESET button
17.
AUX IN (auxiliary input) jack
18.
USB port
19. SD Card slot
20. Disc slot
11 4 3
7
5 6
button
button
20
8 9 10
15 18
19 17 16
