Summary of Contents for ASROCK uBOX-110
- Page 1 User Manual...
-
Page 2: Copyright Notice
(including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product. -
Page 3: Contact Information
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at www.ASRock.com; or you may contact your dealer for further information. -
Page 4: Table Of Contents
Contents Chapter 1 Introduction Package Contents Product Specifications Block Diagram Chapter 2 Product Overview Inside View Front View Rear View Chapter 3 Hardware Installation Removing the Covers Installing Memory Modules (SO-DIMM) Installing the mSATA Module Inserting the SMA WiFi Antennas (Optional) Installing the WiFi Module (Optional) Installing the WiFi Antennas (Optional) Replacing the Covers... -
Page 5: Chapter 1 Introduction
In case any modifications of this documentation occur, the updated version will be available on ASRock’s website without further notice. If you require technical support related to this product, please visit our website for specific information about the model you are using. -
Page 6: Product Specifications
CE, FCC, Class A Environmental Operating Temp 0°C~50°C Storage Temp -20°C~80°C Humidity 10%~90% Mechanical Material Top cover -aluminum extrusion/ Base- metal Dimension 135*116*25.4 mm Weight Mounting VESA 75/100 mounting bracket * For detailed product information, please visit our website: http://www.asrock.com... -
Page 7: Block Diagram
1.3 Block Diagram... -
Page 8: Chapter 2 Product Overview
Chapter 2 Product Overview This chapter provides diagrams showing the location of important components of the uBOX-110. 2.1 Inside View mini-PCIe/mini-SATA slot Rear Panel SO-DIMM sockets mini-PCIe slot Front Panel... -
Page 9: Front View
2.2 Front View Description Power Button Reset Button USB 2.0 Port 3.5mm Audio Jack (CTIA Standard) LAN RJ-45 Port (LAN2) LAN RJ-45 Port (LAN1) * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port... -
Page 10: Rear View
2.3 Rear View No. Description No. Description DC Jack Port (+12V Only) USB 3.0 Port Micro HDMI Port Micro USB 2.0 Port (USB2_2) HDMI Port... -
Page 11: Chapter 3 Hardware Installation
Chapter 3 Hardware Installation This chapter provides step-by-step procedures on how to install components. Installation Procedures Removing the Covers Installing the Memory Modules (SO-DIMM) Installing the mSATA module Inserting the SMA WiFi Antennas (Optional) Installing the WiFi Module and the WiFi Antennas (Optional) -
Page 12: Removing The Covers
3.1 Removing the Covers 1. Remove the four screws on the bottom case. 2. Remove the two screws on each side to release the rear panel. 3. Lift up and remove the top cover. -
Page 13: Installing Memory Modules (So-Dimm)
3.2 Installing Memory Modules (SO-DIMM) This motherboard provides two 204-pin DDR3 (Double Data Rate 3) SO-DIMM slots. Please install the SO-DIMM module into the DDR3_A2 for the first priority. It is not allowed to install a DDR or DDR2 memory module into a DDR3 slot; otherwise, this motherboard and SO-DIMM may be damaged. -
Page 14: Installing The Msata Module
3.3 Installing the mSATA Module 1. Align and gently insert the mSATA Module into the mini-PCIe/mini-SATA slot (MINI_ PCIE2). 2. Tighten the screw that holds the module in place. 3. Tighten the screw that holds the module in place. *Move the stando based on the module type. -
Page 15: Inserting The Sma Wifi Antennas (Optional)
3.4 Inserting the SMA WiFi Antennas (Optional) 1. Insert the RP-SMA Wi-Fi Antenna Connectors to the antenna ports. 2. Then fasten the screw nuts to secure the antenna. -
Page 16: Installing The Wifi Module (Optional)
3.5 Installing the WiFi Module (Optional) 1. Align and gently insert the WiFi Module Card into the mini PCI Express slot (MINI_ PCIE1). 2. Tighten the screw that holds the card in place. -
Page 17: Installing The Wifi Antennas (Optional)
3.6 Installing the WiFi Antennas (Optional) 1. Attach the SMA Wi-Fi Antenna Cables to the WiFi Module. 2. Connect the two WiFi 2.4/5 GHz Antennas to the antenna connectors. Turn the antenna clockwise until it is securely connected. 3. Set the WiFi 2.4/5 GHz Antenna at 90-degree angle. -
Page 18: Replacing The Covers
3.7 Replacing the Covers 1. Replace the boom cover. 2. Secure the four screws at the boom. 3. Secure the the two screws on each side. -
Page 19: Using The Wall Mount Bracket
3.8 Using the Wall Mounting Bracket 1. Attach the Wall Mounting Bracket to the base of uBOX-110 using the four screws. *Choose mounting holes A (75 mm × 75 mm) or B (100 mm × 100 mm) depending on the mounting hole pattern of your LCD screen. -
Page 20: Chapter 4 Motherboard
Chapter 4 Motherboard 4.1 Motherboard Layout 2 3 4 1213 14 PNL_PWR1 COM2 BLT_VOL1 PWR_JP1 CLRMOS1 JGPIO_PWR1 BLT_PWM1 BKT_PWR1 PWRBTN1 USB2_2 COM1 BLT_PWR1 LPC1 JGPIO1 BUZZ1 SET_CM1 JGPIO_SET1 DDR3 (Support DDR3L Only) RESET1 USB3_1 USB2_1 AUDIO1 VGA1 LAN2 HDMI2 LAN1 MSATA_SEL1 DC_JACK1 mini-PCIe / mini-SATA... - Page 21 No. Description Backlight Control Level (BLT_PWM1) Clear CMOS Header Backlight Power Select (LCD_BLT_VCC) (BKT_PWR1) 2-Pin Buzzer Header Backlight & Amp Volume Control (BLT_VOL1) Inverter Power Control Wafer (BLT_PWR1) LVDS Panel Connector COM1 Pin9 PWR Setting Panel Power Select (LCD_VCC) (PNL_PWR1)
-
Page 22: Motherboard Specifications
4.2 Motherboard Specifications Form Dimensions 111.76 x 116.84 mm (10 layer) Factor ® Intel new Atom Baytrail-I Supports Hyper-Threading Technology Default E3826 Dual Core Processor Optional E3845/3815 Quad/Single Core Processor Processor Core Number (By CPU, Max 4) System Max Speed (By CPU) L2 Cache (By CPU) - Page 23 12V DC Jack AT/ATX Supported Power AT: Directly PWR on as power input ready Requirements Power On ATX: Press button to PWR on after power input ready Environment Temperature 0ºC – 60ºC * For detailed product information, please visit our website: http://www.asrock.com...
-
Page 24: Jumpers Setup
4.3 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins. - Page 25 Panel Power Use this to set up the VDD Selection (LCD_ power of the LVDS connector. VCC) 1-2: +3V (5-pin PNL_PWR1) 2-3: +5V (see p.15, No. 9) 3-4: +5V 4-5: +12V Backlight Power Selection Use this to set up the backlight (LCD_BLT_VCC) power of the LVDS connector.
-
Page 26: Onboard Headers And Connectors
4.4 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. SATA2 Connector This Serial ATA2 (SATA2) (SATAII_1) connector supports SATA data SATAII_1... - Page 27 LVDS Panel Signal Name Signal Name Connector LCD_VCC LCD_VCC (40-pin LVDS1) LVDS_A_ (see p.15, No. 7) DATA0# LVDS_A_ GND1 DATA0 LVDS_A_ LVDS_A_ DATA1# DATA1 LVDS_A_ GND6 DATA2# LVDS_A_ GND2 DATA2 LVDS_A_ LVDS_A_ DATA3# DATA3 GND7 LVDS_A_CLK# LVDS_A_CLK GND3 LVDS_B_...
- Page 28 Backlight & Amp Volume Signal Name Control GPIO_VOL_UP (7-pin BLT_VOL1) GPIO_VOL_DW PWRDN (see p.15 No. 5) GPIO_BLT_UP GPIO_BLT_DW Inverter Power Control Signal Name Wafer (6-pin BLT_PWR1) (see p.15 No. 6) CON_LBKLT_ CON_LBKLT_EN LCD_BLT_VCC LCD_BLT_VCC LPC Header This connector supports (17-pin LPC1) Trusted Platform Module (see p.15 No.
- Page 29 Buzzer Header (2-pin BUZZ1) SPKR (see p.15 No. 4) VGA Connector (10-pin VGA1) (see p.15 No. 21) Signal Signal Signal Signal Signal Name Name Name Name Name GREEN BLUE HSYNC DDC_CLK DDC_ VSYNC DATA...
-
Page 30: Expansion Slots (Mini-Pcie And Mini-Pcie/Mini-Sata Slots)
4.5 Expansion Slots (mini-PCIe and mini-PCIe/mini-SATA Slots) There is 1 mini-PCIe slot and 1 mini-PCIe/mini-SATA slot on this motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.
