ASROCK UTX-110 Settings Manual

*15G06M020001AK*
P/ N: 15G06M020001AK V1.1
UTX-110
UTX-111
32
The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
31
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
30
29
28
27
1 : Backlight Control Level
(BLT_PWM1)
1-2 : +3V
2-3 : +5V
2 : Clear CMOS Header
1-2 : Normal
2-3 : Clear CMOS
3 : Backlight Power Select
(LCD_BLT_VCC) (BKT_PWR1)
1-2 : +5V
2-3 : +12V
4 : 2-Pin Buzzer Header
1
SPKR
+5V
5 : Backlight & Amp Volume Control
(BLT_VOL1)
PIN
1
1
2
3
4
5
6
7
6 : Inverter Power Control Wafer
(BLT_PWR1)
PIN
1
1
2
3 CON_LBKLT_CTL
4 CON_LBKLT_EN
5
6
Jumpers and headers setting guide
1 2 3 4
BLT_VOL1
CLRMOS1
1
1
BLT_PWM1 BKT_PWR1
1 1
1
USB2_2
BLT_PWR1
1 BUZZ1
USB3_1
1
VGA1
HDMI2
DC_JACK1
mini-PCIe / mini-SATA
Industrial
7 : LVDS Panel Connector
PIN Signal Name
1 LCD_VCC
3 +3V
5 N/A
7 LVDS_A_DATA0
9 LVDS_A_DATA1#
11 GND6
13 LVDS_A_DATA2
15 LVDS_A_DATA3#
17 GND7
19 LVDS_A_CLK
21 LVDS_B_DATA0#
23 GND8
25 LVDS_B_DATA1
27 LVDS_B_DATA2#
29 DPLVDD_EN
31 LVDS_B_DATA3
Signal Name
33 LVDS_B_CLK#
GPIO_VOL_UP
35 GND9
GPIO_VOL_DW
37 CON_LBKLT_CTR
PWRDN
39 LCD_BLT_VCC
GPIO_BLT_UP
GPIO_BLT_DW
8 : COM1 Pin9 PWR Setting
GND
1-2 : +5V
GND
2-3 : +12V
9 : Panel Power Select (LCD_VCC)
Signal Name
(PNL_PWR1)
GND
1-2 : +3V
GND
2-3 : +5V
3-4 : +5V
4-5 : +12V
LCD_BLT_VCC
LCD_BLT_VCC
6 7 8 9
5
PNL_PWR1
1
1
1
1
1
DDR3 (Support DDR3L Only)
1
SATAII_1
26
PIN Signal Name
2 LCD_VCC
4 N/A
6 LVDS_A_DATA0#
8 GND1
10 LVDS_A_DATA1
12 LVDS_A_DATA2#
14 GND2
16 LVDS_A_DATA3
18 LVDS_A_CLK#
20 GND3
22 LVDS_B_DATA0
24 LVDS_B_DATA1#
26 GND4
28 LVDS_B_DATA2
30 LVDS_B_DATA3#
32 GND5
34 LVDS_B_CLK
36 CON_LBKLT_EN
38 LCD_BLT_VCC
40 LCD_BLT_VCC
1
10 1213 14
11
COM2
PWR_JP1
1
JGPIO_PWR1
1
15
PWRBTN1
1
COM1
16
JGPIO1
SET_CM1 1
JGPIO_SET1
1 CI1
17
RESET1
1 CI2
18
19
20
USB2_1
21
AUDIO1
22
LAN2
LAN1
23
MSATA_SEL1
SATA_PWR1
25
24
COM1, 2 Headers
10 : COM2
11 : COM1
Signal Signal
PIN PIN PIN
Name Name
1 DDCD# 3 TTXD 5
2 RRXD 4 DDTR# 6
* This motherboard supports RS232/422/485 on COM1 port. Please refer to below
table for the pin definition. In addition, COM1 port (RS232/422/485) can be adjusted
in BIOS setup utility > Advanced Screen > Super IO Configuration. You may refer to
page 25 of our user manual for details.
COM1 Port Pin Definition
PIN RS232
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 +5V/+12V
12 : ATX/AT Mode Select
1-2 : AT Mode
2-3 : ATX Mode
13 : Digital Input / Output Power Select
1-2 : +12V
2-3 : +5V
14 : Digital Input / Output Pin Header
PIN Signal Name PIN Signal Name
1 JGPIO_PWR
1
3 SIO_GP27
5 SIO_GP26
7 SIO_GP25
9 SIO_GP24
1
2
Signal Signal Signal
PIN PIN
Name Name Name
GND 7 RRTS# 9 DUMMY
DDSR# 8 CCTS# 10 DUMMY
RS422 RS485
TX- RTX-
RX+ N/A
TX+ RTX+
RX- N/A
GND GND
N/A N/A
N/A N/A
N/A N/A
N/A N/A
2 GND
4 SIO_GP23
6 SIO_GP22
8 SIO_GP21
10 SIO_GP20
