smart-e SLX-111 User Manual

Cat5 av extender smartlynx x+
Hide thumbs Also See for SLX-111:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
The Clearer Picture
SmartLynx X+
Cat5 AV Extender
Model No:
SLX-111

User Guide

Part No: SLX111UG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLX-111 and is the answer not in the manual?

Questions and answers

Related Manuals for smart-e SLX-111

Summary of Contents for smart-e SLX-111

  • Page 1: User Guide

    The Clearer Picture SmartLynx X+ Cat5 AV Extender Model No: SLX-111 User Guide Part No: SLX111UG...
  • Page 2 Smart-e will not be liable for errors contained herein or for inciden- tal or consequential damages in connection with the furnishing, per- formance or use of this material.

  • Page 3: Table Of Contents

    Table of Contents Introducing SmartLynx ..........1 What ‘s in the box ............1 What is SmartLynx ............2 Why is SmartLynx necessary ......... 2 How does SmartLynx work..........2 Installation and Operation ...........3 Transmitter ..............3 Receiver ..............6 Appendix ..............9 Specifications ...............

  • Page 4: Introducing Smartlynx

    If any of the accessories listed below are missing please contact the Smart-e dealer you purchased products from or contact Smart-e customer support at:...

  • Page 5: What Is Smartlynx

    SDTV How does SmartLynx work? The Smart-e SmartLynx is a transmitter and receiver pair designed to extend video, stereo audio and IR/RS232 signals over (UTP) unshielded twisted pair category 5 (Cat5) cabling. They are supplied with a UK power supply and consist of: a transmitter with a video input (connectors vary by model), an audio input and a Cat5 output and;...

  • Page 6: Installation And Operation

    Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX Page 3 +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...

  • Page 7: Transmitter

    3. Setting Jumpers on Transmitter to correct position The diagram below details how to correctly set the jumpers for the required video type. Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX Page 4 +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...
  • Page 8 Capacitance: 14 pf/ft (46.2 pf/m) Conductor Gauge: 24 AWG Impedance: 100 +/- 15 ohms 4 - Pair Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX Page 5 +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...
  • Page 9 If RS232 control is required then connect to the display via the 3.5mm minijack on the receiver using a CAB-J19-1M. Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX Page 6 +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...
  • Page 10 Please note: connecting the IR ‘eye’ will prevent the return RS232 path from the display Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX Page 7 +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...
  • Page 11 NB. Always use screws with heads larger than the holes. ‘MOUNTING-HOLES’ ‘MOUNTING-HOLES’ Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX Page 8 +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...

  • Page 12: Receiver

    120 x 94 x 23 mm Receiver 120 x 94 x 23 mm Weight Transmitter 0.2kg Receiver 0.2kg Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX Page 9 +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...
  • Page 13 Is the audio input level too high? The audio level should be set to line level (0dB or 700mV peak to peak) to prevent interference. Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX Page 10 +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...

  • Page 14: Appendix

    Customer is responsible for maintaining proof of date of purchase. Smart-e warranty covers only those defects which arise as a result of nor- mal use of the product, and do not apply to any: a. Improper or inadequate maintenance or modifications b.

  • Page 16: Partial Product List

    SmartNet-X+ SNX-8x8+ 8 x 8 Distribution Matrix SmartNet-X+ SNX-16x16+ 16 x 16 Distribution Matrix (Up to 256 x 256) Smart-e (UK) Ltd, Ranmore Manor, Ranmore Common, Dorking, Surrey, RH5 6SX +44 (0) 1483 283365 Fax: +44 (0) 1483 281511, www.smart-e.co.uk...
