- Page 2 Smart-e will not be liable for errors contained inside this manual, or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
-
Page 3: Table Of Contents
Table of Contents Introducing Smart Digital Solutions (SDS) ......... What’s in the box ................... 1 What is the SDS-901? ................. 2 Why is the SDS-901 necessary? ............2 How does the SDS-901 work? ..............2 Installation and Operation Transmitter ......................3 Receiver ........................ -
Page 4: What's In The Box
Introducing SDS-901 CAT 5 AV Extender What‘s in the box? Thank you for buying the Smart-e SDS CAT 5 AV Extender. Depending on the configuration of your system various quantities of the parts below may be included in your shipment. -
Page 5: What Is The Sds-901
The SDS-901 allows the transmission of AV signals over a standard CAT 5 –8 UTP cable over distances of up to 100m. The actual distance is a func-... -
Page 6: Installation And Operation
This is accomplished by connecting the devices directly to the computer and checking that the devices operate as desired without the SDS-901 system. Potential System Set-up: Install CAT 5 wiring between desired locations. In order to minimize system operation difficulties, avoid routing the system cables near fluorescent lights, air conditioners, or machines that may create electrical noise. - Page 7 Installation and Operation 2. Connect Transmitter to the video signal source Connect the HDMI output of the source device to the input of the transmitter using a high quality HDMI cable If needed connect the audio input to either an analogue or a TOSlink output of the AV source.
-
Page 8: Transmitter
Installation and Operation 3. Connecting Infra-red and RS232 to the transmitter The Infra-red is accessed via a 3.5mm mono jack on the left hand side of the rear panel. Using the appropriate interconnecting device (SM- LED) connect the jack end to the SDS-TX901 and stick the other end to the AV device you want to control, making sure the emitter is placed close to the IR receiver in the AV device. - Page 9 Installation and Operation 4. LED and Audio function There are 4 LED indicators on the SDS-901 pair Green on RJ45—shows 24V inline power Yellow on RJ45—pulses showing correct working iii) Green on front panel—show internal 5Volts Green next to the audio connector—on for analogue, off for...
- Page 10 Installation and Operation 5. System Power up Turn the system on by plugging in the power adapter to the SDS-900 Transmitter (or Receiver if preferred) Power up your computer. Observe both transmitter and receiver power LED are ON, and source device is switched on. 6.
-
Page 11: Receiver
Installation and Operation of Receiver 7. Connecting SDS-RX901 HDMI to the display device Making sure that the CAT 5 cable is connected to the transmitter output, connect the cable to the RJ45 socket on the receiver unit. If the cable connection is correct the power all 3 LEDs will illuminate (power is sent up the CAT 5 cable). - Page 12 Installation and Operation of Receiver 8. Connecting SDS-RX901 to Infra-Red and RS232 control If using the receiver to transmit Infra-Red signals back down the cable to the transmitter unit then connect an ‘eye’ (SM-EYEN) to the jack position as shown in the diagram below. If using RS232 connect control cable to the mini-jack input as shown in the diagram below, using a CAB-JDM-1M...
-
Page 13: Mounting The Units
Mounting of Units 9. Mounting the units There is a 19” rack mounting kit available (RMK-191-900) which allows for up to 4 units to be assembled into a 1U shelf. Attachment is via 2 x M3 bushes in the front panel. These are fitted for both the transmitter and receiver units. - Page 14 Technical Information SDS-901 Video Input Signal Type......………….. HDMI, DVI & DisplayPort Multimode Formats…………………………………..HDMI a/Deep Colour 3D, 4K, 2K & 1080p Signal Type - Connector………….. HDMI Audio Input Signal Type…………………………………. Analogue stereo or TOSlink Analogue BW……………………………. 20-20kHz Formats………………………………………. AES/EBU stereo or Dolby 5.1 Connector……………………………………...
-
Page 15: Appendix
Customer is responsible for main- taining proof of date of purchase. Smart-e warranty covers only those defects which arise as a result of normal use of the product, and do not apply to any: a. -
Page 16: Partial Product List
Partial Product List Product Range Product Code Description SmartLynx - X SLX-100 Transmitter and Receiver Pair SLX-411 Transmitter and Receiver Pair SmartLynx-X + SLX-111 100m Transmitter and Receiver Pair with RS232/IR SLX-214 300m Transmitter and Receiver Pair with RS232/IR SLX-100 300m Transmitter and Receiver Pair SmartCast - X SCX-TX600...
