Summary of Contents for smart-e 4K-866
- Page 2 4K-866 USER MANUAL V1.0 SYMBOLS To ensure the safe and correct use of equipment, we use a range of symbols on the equipment and in the manuals. These symbols demonstrate the risk of physical harm or possible damage to property for the user or others and provide guidance on standards and disposal.
- Page 3 4K-866 USER MANUAL V1.0 WARNING In order to ensure the reliable performance of the equipment and the safety of the user, please observe the following matters during the process of installation, use and maintenance. : INSTALLATION ◆ Please do not use this product in the following places: places with high levels of dust or soot; places with high electric conductivity;...
-
Page 4: Table Of Contents
4K-866 USER MANUAL V1.0 CONTENTS FUNCTION ..............................5 FEATURES ..............................6 CHASSIS PANEL DESCRIPTION ......................7 4K-TX866 ..............................7 4K-RX866 ..............................8 APPLICATION DIAGRAM ......................... 9 WHAT IS INCLUDED ..........................10 ACCESSORIES ............................11 (IR RX) ........................11 NFRA RED RECEIVERS (IR TX) ....................... -
Page 5: Function
This means the 4K-866 can be used to integrate in to a wider control system or be used to send commands directly to a screen or a projector from a serial control device. -
Page 6: Features
4K-866 USER MANUAL V1.0 2 FEATURES ▪ Small form factor – Only 25mm high ▪ Utilizes easy to install and relatively inexpensive CAT 5e-8 cabling ▪ Support HDMI up to 340MHz TMDS clock ▪ HDCP/EDID/DCC transparent link ▪ HDMI resolutions 4K, 2K & 1080p ▪... -
Page 7: Chassis Panel Description
4K-866 USER MANUAL V1.0 3 CHASSIS PANEL DESCRIPTION 3.1 4K-TX866 1. 24V lockable DC jack input 2. Infra-red input port 3. Infra-red output port 4. HDBaseT link indicator LED 5. HDBaseT output port 6. HDMI data indicator LED 7. HDMI hot-plug detect indicator LED 8. - Page 8 4K-866 USER MANUAL V1.0 3.2 4K-RX866 1. 24V lockable DC jack input 2. Infra-red input port 3. Infra-red output port 4. HDBaseT link indicator LED 5. HDBaseT input port 6. HDMI data indicator LED 7. HDMI hot-plug detect indicator LED 8.
-
Page 9: Application Diagram
4K-866 USER MANUAL V1.0 4 APPLICATION DIAGRAM © 2018 Smart-e (UK) Ltd www.smart-e.co.uk PAGE | 9... -
Page 10: What Is Included
➢ 2x IR transmitters ➢ 2x RS232 3-pin plugs Please ensure you have all parts listed above prior to installation, if any components are missing or damaged please contact Smart-e support immediately. © 2018 Smart-e (UK) Ltd www.smart-e.co.uk PAGE | 10... -
Page 11: Accessories
4K-866 USER MANUAL V1.0 6 ACCESSORIES 6.1 INFRA-RED RECEIVERS (IR RX) The infra-red receiver for the 866 range consists of a photo diode at one end and a 3.5mm stereo jack on the other. The photo diode accepts infra-red signals from an infra-red emitting handset and the 3.5mm jack takes this signal to the TX or RX866 to the 3.5mm socket as indicated below. -
Page 12: Infra-Red Transmitters (Ir Tx)
4K-866 USER MANUAL V1.0 6.2 INFRA-RED TRANSMITTERS (IR TX) The infra-red transmitter for the 866 range consists of an infra-red emitting diode at one end and a 3.5mm stereo jack at the other. The 3.5mm stereo jacks takes infra-red signals from the 866 device and send them to the IR emitting diode, the IR emitting diode should then be attached in close proximity of the IR receiver of the device you wish to control. -
Page 13: Rs232 Plugs
4K-866 USER MANUAL V1.0 6.3 RS232 PLUGS Each 866 device is supplied with a 3-pin phoenix screw lock plug to insert in to the receptacle on the 866 as indicated below. The pin out is indicated on the silk screen of the 866 device, you should strip back approximately 10mm of cable and then secure by screwing in to the appropriate space of the screw lock plug. -
Page 14: Power Supply And Mains Adapter Plug
Above is a picture of the 24V power supply sent with each individual TX or RX 866 unit when purchased individually, if items are purchased as a pair (4K-866) then one unit will be sent to power both units through PoC. -
Page 15: Basic Setup
1. Test the CATx cables to be used for HDBaseT link and if required Ethernet. This can be achieved with a cable tester, optionally you could purchase a 4K-9000 HDBaseT tester from Smart-e which is purpose built to test for HDBaseT installations. Ensure cables are terminated correctly and preferably to the specification as outlined in section 9 of this manual. -
Page 16: Status Leds
4K-866 USER MANUAL V1.0 8 STATUS LEDS 8.1 HDBASET LINK LED A HDBaseT indicator LED is located next to the RJ45 HDBaseT connector on both the TX and RX variants of the 866. This is the primary indication to show the CATx cable used is suitable to enable the TX and RX devices to communicate with one another. -
Page 17: Hdmi Hot-Plug Detect Led
A HDMI compliant source outputs a +5V signal, this signal is detected by a HDMI compliant screen and it responds with a Hot-Plug Detect +5V signal to tell the source a screen is attached. The 4K-866 can handle this mechanism at both the TX and RX end. -
Page 18: Hdbaset Cabling
Smart-e support immediately. HDBaseT signals can be susceptible to noise, causing image loss or snowy effects on output screens. The best way to mitigate against these problems is by using a high quality CATx cable. Smart-e specify cable as below. -
Page 19: Technical Specification
4K-866 USER MANUAL V1.0 10 TECHNICAL SPECIFICATION 10.1 4K-TX866 Audio and Video Ports Input Ports 1x HDMI Output Ports None Serial port Serial control interface RS-232, 3 pin female phoenix connector Baud rate and protocol Baud rate: 115200, data bits: 8 bits, stop bits: 1 bit, no parity check bit... - Page 20 4K-866 USER MANUAL V1.0 Fall Time <0.3T bit (20-80%) Maximum Transmission Delay 5ns (+/- 1ns) Signal Strength T.M.D.S +/- 0.4V p-p Minimum/Maximum Level T.M.D.S 2.9V/3.3V Impedance 50Ω EDID Pass-through Maximum DC Offset error 15mV Maximum Input cable length 15 meters (always use high quality cable)
- Page 21 4K-866 USER MANUAL V1.0 10.2 4K-RX866 Audio and Video Ports Input Ports None Output Ports 1x HDMI Serial port Serial control interface RS-232, 3 pin female phoenix connector Baud rate and protocol Baud rate: 115200, data bits: 8 bits, stop bits: 1 bit, no parity check bit...
- Page 22 4K-866 USER MANUAL V1.0 Signal Strength T.M.D.S +/- 0.4V p-p Minimum/Maximum Level T.M.D.S 2.9V/3.3V Impedance 50Ω EDID Pass-through Maximum DC Offset error 15mV Maximum Input cable length Maximum Output cable length 15 meters (always use high quality cable) HDBaseT port specification...
