OPERATING YOUR APPLIANCE

Temperature Control and Display

1. The temperatures in upper zone and lower zone can be independently controlled and displayed.
2. The temperature in either zone can be controlled between 39°F to 61°F (4℃ to 16℃). (The zone
temperature may have a tolerance of +/-5°F (+/-3℃) from setting depending on different loading
and ambient conditions.)
3. The temperature display, indicator
(left side) are for upper zone of the wine cooler.
4. The temperature display, indicator
(right side) are for lower zone of the wine cooler.
5. The indicators
Indicators Lights
● When it lights, the indicator
● When it lights, the indicator
which can be used to unlock.
● When it lights, the indicator
indicator will go off when the set temperature is met.

Standby

1. Whenever the unit is switched on, all the display and indicators will light for 3 seconds with a beep
sound. Then the unit will automatically resume its previous setting when it was switched off. If the
unit was previously in "stand by" mode when switched off, it will resume the mode of "stand by"
and the indicator
2. You can manually set your unit to the mode of "stand by" by pressing and holding both pads
(warmer) and (colder) for the lower zone for approximately 3 seconds, provided the pads are
unlocked and no any other setting operation is in process (Display does not flash). The indicator
will light to confirm this setting.

Lock and Unlock

If no pad is pressed within 1 minute then all control pads will be automatically locked except the
pad (lock), which can be used to unlock. You can also manually lock them by pressing the
pad (lock) before they are automatically locked.
Under locked condition, no pad pressing will function but the indicator
to remind you that the pad being pressed is locked.
A pad functions only when it is unlocked. To unlock, press and hold the pad
seconds until the indicator

Temperature setting

• In normal condition, the temperature display indicates instant temperature of the
corresponding zone. During the setting operation, the temperature display flashes to remind
that temperature setting is in process.
• The temperature in both upper zone and lower zone can be set separately by pressing pads
(warmer) or
zones can be set anywhere between 39°F to 61°F (4℃ to 16℃).
• When the pad
or decrease in an increment of one degree. If the pad
and held for 2 seconds, the temperature displayed will increase or decrease in a speed of one
degree per half second.
• During the setting operation, the temperature displayed flashes until no pad is pressed within
approximately 3 seconds. Then your last setting is recorded and confirmed by that the display
stops flashing but to indicate instant temperature of that zone.
,
control pads
,
control pads
and , and the control pads
indicates the unit is in the mode of "stand by".
indicates all control pads are locked except the pad
indicates the corresponding zone is in refrigeration cycle. The
will light.
goes off.
(colder) respectively corresponding to that zone. The temperature of both
(warmer) or (colder) is pressed, the temperature displayed will increase
(warmer) and
(warmer) and
(lock) and (light) are for both zones.
(warmer) or
6
(colder) near the symbol
(colder) near the symbol
(lock),
will flash for 5 seconds
(lock) for 3
(colder) is pressed
