Wine Cooler
Beverage Cooler
Wine Cooler Model No. MCWC50DBT
Beverage Cooler Model No. MCBC580DBT
. Before Putting Into Use . . . . . . . . . . . . . . . . .
. Important . . . . . . . . . . . . . . . . . . . . . . . .
. Installation . . . . . . . . . . . . . . . . .
. Description of the Appliance . . . . . . . . . . . . . . .
. Temperature Control . . . . . . . . . . . . . . . . . . .
. Maintenance and Cleaning . . . . . . . . . . . . . . . .
. Trouble Shooting Guide . . . . . . . . . . . . . . . . .
. Changing The Reversible Door . . . . . . . . . . . . . . . . . .
. Appliance Warranty . . . . . . . . . . . . . . . . . .
To ensure proper use of this appliance and your safety, please read the following
instructions completely before operating this appliance.
2
2
3
4
5
6
7
9
10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Magic Chef MCBC580DBT
Summary of Contents for Magic Chef MCBC580DBT
-
Page 1: Table Of Contents
Beverage Cooler Wine Cooler Model No. MCWC50DBT Beverage Cooler Model No. MCBC580DBT . Before Putting Into Use ....Important ...... -
Page 2: Temperature Control And Display
Description of the Appliance ... . 4 Wine Cooler MCWC50DBT Beverage Cooler MCBC580DBT Temperature Control and Display ..5 Wine Cooler MCWC50DBT Beverage Cooler MCBC580DBT Maintenance and Cleaning . - Page 3 Before Putting Into Use · Before connecting the appliance to electrical power supply, leave it to stand for about 4 hours, which will reduce the possibility of malfunctions in the cooling system due to transport handling. · Clean the appliance thoroughly, especially in the interior (See Cleaning and Maintenance).
-
Page 4: Installation
Installation BUILT-IN INSTALLATION The cutout depth must be 24". The cutout dimensions shown allows for a full door swing and access to the pull-out racks when installed as a built-in. The appliance can be installed freestanding. If installing between frameless cabinets, a 1/2" wide filler strip or side panel may be needed on hinge side. -
Page 5: Description Of The Appliance
6 bottles with the necks facing the front. Interior Light The appliance has an interior light (E14 socket, max. 15W) for easy interior visibility. Beverage Cooler MCBC580DBT Engaged beverage shelves There are three glass shelves to store beverages. All the shelves have tabs to engage the cabinet on both sides. -
Page 6: Temperature Control
Celsius and Fahrenheit by pressing and holding the ▲ pad for approximately 10 seconds. The following is applicable to both MCWC50DBT and MCBC580DBT: To return the controller back to the Factory Setting, press and hold the ▼ pad, within one second press ▲... -
Page 7: Maintenance And Cleaning
Maintenance and Cleaning Automatic Defrosting of the Appliance There is no need to defrost the appliance, because ice depositing on the inner back wall is defrosted automatically. Ice build-up on the inner back wall during the compressor operation will defrost automatically (when the compressor has cycled off) . -
Page 8: Trouble Shooting Guide
Trouble-Shooting Guide Sometimes you may come across minor problems that in most cases do not require a service call and can be easily eliminated. The problem may have resulted from improper handling and / or installation of the appliance. Please refer to the below trouble-shooting guide to assist you in identifying the possible cause and solution to your problem. - Page 9 Water is Leaking From the Appliance If the discharge water outlet is clogged, or the defrost water drips over the channel, water will leak from the appliance. Clean the clogged outlet. Manually defrost the increased ice layer ( see ice Formation on the Inner rear Wall ). Noise Cooling in this appliance is made possible by cooling the system using a compressor, which...
-
Page 10: Changing The Reversible Door
CAUTION: To avoid personal injury to yourself and/or property, we recommend someone assist you during the door reversal process. 1. Remove the top hinge assembly and keep them for later use. 2. Remove the bottom hinge assembly and keep them for later use. -
Page 11: Appliance Warranty
Type of Service MCWC50DBT One-Year One-Year Five Years In Home MCBC580DBT One-Year One-Year Five Years In Home For Service or Assistance please call 888 775-0202 or visit us on the web at www.magicchef-ewave.com. To avoid delays when obtaining warranty service,...
