Summary of Contents for Monoprice 13809
-
Page 2: Table Of Contents
CONTENTS SAFETY WARNINGS AND GUIDELINES ................. 3 FEATURES ..........................4 PACKAGE CONTENTS ......................4 CONNECTIONS ........................5 CONTROLS ..........................6 SETUP ............................7 MONITOR STAND ........................7 VIEWING ANGLE ADJUSTMENT ..................... 8 ON-SCREEN DISPLAY (OSD) MENU ..................9 Basic Menu Operation ......................9 Quick Source Selection Menu .................... -
Page 3: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Do not place the monitor on an unstable surface where it could fall and cause either personal injury or damage to the monitor and/or other equipment. Do not expose the monitor to water or moisture of any kind. Do not place objects containing moisture, such as a glass or vase, where it could tip over and spill into or onto the monitor. -
Page 4: Features
PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. 1x 28" 4K UHD LED monitor 1x Stand base... -
Page 5: Connections
CONNECTIONS Dual Link DVI-D video input HDMI/MHL HDMI 2.0 video input with MHL support DisplayPort DisplayPort 1.2 video input VGA video input Line In 3.5mm TRS stereo audio input DC In DC power input HDMI Note: This monitor is capable of displaying the full 4K resolution (3840x2160@60Hz) using an HDMI connection. -
Page 6: Controls
CONTROLS 1. -/ : If the OSD menu is displayed and an entry has been opened for editing, pressing the -/ button decreases the selected value. If the OSD is not displayed, pressing the -/ button opens the volume adjustment control. With either the brightness or volume adjustment control displayed, pressing the -/ button decreases the brightness or volume. -
Page 7: Setup
SETUP 1. Either install the stand base or remove the stand neck to use a desk or wall mount by following the instructions in the MONITOR STAND section below. 2. Connect one or more video cable(s) from your source device(s) to the monitor's input(s). The monitor has four video inputs (VGA, DVI, HDMI-MHL, and DisplayPort) and can simultaneously display up to four video sources. -
Page 8: Viewing Angle Adjustment
If you want to use the monitor with desk or wall mount, you can remove the both the stand base and stand neck by performing the following steps: 1. Place a blanket or towel on a flat surface, such as a table or the floor. 2. -
Page 9: On-Screen Display (Osd) Menu
ON-SCREEN DISPLAY (OSD) MENU Press the MENU button to access the OSD menu. Basic Menu Operation -/ : When the OSD menu is displayed and an item has been opened for editing, pressing the -/ button decreases the selected value. +/ : When the OSD menu is displayed and an item has been opened for editing, pressing the +/ button increases the selected value. -
Page 10: Quick Source Selection Menu
Quick Source Selection Menu Press the SELECT button to activate the Quick Source Selection menu. Move the highlight to the desired input using the UP and DOWN buttons, then press the SELECT button again to select the highlighted source. The available sources are VGA, Dual-Link DVI-D, HDMI-MHL (v2.0), and DisplayPort (v1.2) (DP). -
Page 11: Brightness/Contrast Menu
Brightness/Contrast Menu Brightness: Adjusts the image brightness. The adjustment range is 0 to 100. Contrast: Adjusts the image contrast. The adjustment range is 0 to 100. DCR: DCR stands for Dynamic Contrast Ratio, which is a circuit that increases the effective picture contrast by changing the light intensity of the LED backlighting. -
Page 12: Color Setting Menu
Color Setting Menu Gamma: You can select one of the five gamma curves. The possible options are 1.8, 2.0, 2.2, 2.4, and 2.6. Picture Mode: You can select one of four picture modes for optimal display of different types of content: Standard: The best choice for documents, office work, programming, and text editing. -
Page 13: Picture Quality Setting Menu
Picture Quality Setting Menu Bypass: Allows you to enable or disable the Picture Quality settings on this page, without the need to make individual adjustments. The possible options are On and Off. Sharpness: Allows you adjust the picture sharpness. The adjustment range is 0 to 100. Response time: Allows you to change the response time. -
Page 14: Display Menu
Display Menu Aspect Ratio: Allows you to set the aspect ratio to Wide Screen (16:9), 4:3, or 1:1. H-Position: Adjusts the horizontal position of the image. The adjustment range is from 0 to 100. This option is only available when using a VGA input. V-Position: Adjusts the vertical position of the image. -
Page 15: Audio Menu
Audio Menu Mute: Allows you to toggle audio muting On or Off. Volume: Sets the volume level. The adjustment range is 0 to 100. Audio Source: Selects the audio input source. The possible options are Line-In (3.5mm stereo input), HDMI, and DP (DisplayPort). -
Page 16: Multi-Window Menu
Multi-Window Menu Multi-Window: Selects the Picture-in-Picture or Picture-by-Picture mode to be used. PiP displays the content from Input 2 in a window laid over the main input image. PbP displays the content of up to four inputs. The available options are: Off, PIPMode, PBP2Win (2 images), PBP3Win (3 images), and PBP4Win (4 images). -
Page 17: Other Menu
Other Menu Horizontal: Adjusts the horizontal position of the OSD menu. The adjustment range is 0 to 100. Vertical: Adjusts the vertical position of the OSD menu. The adjustment range is 0 to 100. Transparency: Adjusts how transparent or opaque the OSD menu will appear on screen. The adjustment range is 0 to 100. -
Page 18: Technical Support
You can also get assistance through email by sending a message to tech@monoprice.com WARRANTY MONOPRICE will replace defective monitors with a new monitor if the RMA is issued within thirty (30) days of the original date of purchase, as shown on the original invoice. Monitors identified as defective after 30 days, but within the twelve (12) month warranty period, will be replaced with refurbished, reconditioned, or used monitors at MONOPRICE'S discretion. - Page 19 Q: The image flashes or distorts. A: Verify that there are no nearby sources or Radio Frequency or Electromagnetic Interference (RFI or EMI). Q: The power LED is glowing blue, but the display is blank. A: Press a key on the keyboard to ensure the computer is not asleep or that a screen saver is active.
-
Page 20: Specifications
SPECIFICATIONS Display Type TN panel with LED backlight Screen Size 28" (711mm) Dot Pitch 0.16 x 0.16 mm Maximum Resolution 3840 x 2160 @ 60Hz (UHD) Brightness 300cd/m Color Support 1.07 billion, including Adobe sRGB Response Time (Tr+Tf) Contrast Ratio (typical) 1000:1 Viewing Angles 170°... -
Page 21: Regulatory Compliance
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Modifying the equipment without Monoprice’s authorization may result in the equipment no longer complying with FCC requirements for Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense. -
Page 22: Notice For Industry Canada
Notice for Industry Canada This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. EU Conformity With Applicable Directives This equipment complies with the essential requirements listed below: ...
