- Page 1 34" Ultrawide Gaming Monitor P/N 42772, 43246 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. •... - Page 3 Unplug this device from the power source when not in use. • Take care to prevent damage to the power cord. Do not allow it to • become crimped, pinched, walked on, or become tangled with other cords. Ensure that the power cord does not present a tripping hazard.
-
Page 4: System Requirements
FEATURES 2x HDMI® 2.0, and 2x DisplayPort® 1.4a video inputs • 3440 x 1440p @ 144Hz maximum video resolution • 21:9 aspect ratio • Quantum LCD display • 4ms response time (MPRT 1ms) • 3000:1 contrast ratio • Up to 400 cd/m² brightness •... -
Page 5: Customer Service
You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com or via email at support@monoprice.com. Check the website for support times and links. -
Page 6: Product Overview
PRODUCT OVERVIEW Controls MENU: If the OSD menu is not displayed, press the MENU button to access the OSD menu. If the OSD menu is displayed, press the MENU button to enter a submenu. If editing a value, press the MENU button to save the edited value. - Page 7 blue when there is no video source, no horizontal or vertical signal is detected, or the voltage is low. If it flashes blue, ensure that your computer is on, that it isn't in sleep mode, and that all video cables are fully inserted and/or properly connected.
-
Page 8: Installing The Stand
INSTALLING THE STAND Perform the following steps to assemble the stand and attach it to the monitor. Remove the foam packaging from the box, then place it face down on a table or other flat surface. Remove all accessories from the packaging and set them aside. Remove the back half of the foam packaging to reveal the back of the monitor. -
Page 9: Removing The Stand
Attach the Adapter Plate to the Stand Assembly using two of the included M5x11 Screws. Reattach the Adapter Plate to the back of the monitor. Remove the monitor from the foam packaging and stand it on a flat surface. Reassemble the foam packaging and place it back in the box. Keep the box and foam packaging in a safe place for future use. - Page 10 INSTALLING A MOUNT Perform the following steps to attach the monitor to a wall or desk mount. If the stand has been installed on the monitor, perform the steps in REMOVING THE STAND section above. Otherwise, press the button on the Adapter Plate, then remove it from the back of the monitor.
-
Page 11: Osd Menu Map
OSD MENU MAP Main Menu Submenu Options Description DP1 (1.4) DP2 (1.4) Selects the primary Input Source None video source. HDMI1 (2.0) HDMI2 (2.0) Adjusts the display Brightness 0~100 brightness Adjusts the display Blacklevel 0~100 black level Brightness/ Contrast Adjusts the display Contrast 0~100 contrast... - Page 12 Main Menu Submenu Options Description Standard Photo Movie Picture Mode Sets the picture mode Game Warm Color Setting Color Sets the color Cool Temperature temperature User Low Blue Sets the level of blue 0~100 Light light filtering 0~100 Adjusts the hue level Adjusts the saturation Saturation 0~100...
- Page 13 Main Menu Submenu Options Description Compensates for gray Dynamic scale display screen Luminous and strengthens the Picture Quality Control expression of gray Setting scale Sets the moving MPRT picture response time Wide Screen Sets the screen aspect Aspect Ratio ratio Display Auto Normal...
- Page 14 Main Menu Submenu Options Description Multi- Sets the multi- PIP Mode Window window mode PBP Mode Selects the secondary Sub Win2 input source for the Input HDMI1 PiP or PbP window HDMI2 Small Adjusts the PiP or PbP PIP Size Medium window size Multi-Window...
- Page 15 Main Menu Submenu Options Description English Chinese Korean Sets the language Language French used in the OSD menu Spanish Japanese Russian Adjusts the horizontal 0~100 position of the OSD H-Position menu Adjusts the vertical 0~100 position of the OSD V-Position menu Sets the overall transparency/...
-
Page 16: Troubleshooting
Main Menu Submenu Options Description DP1.1 Sets the DisplayPort® DP Version DP1.2 version DP1.4 Adaptive- Turns Adaptive-Sync Sync on or off Other Turns HDR on or off Resets the monitor Reset None settings to the factory default values TROUBLESHOOTING Q1: The screen is blank. A1: Ensure that power is on. - Page 17 Q3: The screen is flashing. A3: There is an issue with the power source. Ensure that devices that could cause magnetic interference are a safe distance away. Q4: There is color bleeding, distortion, or other unusual effects. A4: Check the video cable connections. Connect to another video source for comparison.
-
Page 18: Technical Support
TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates. - Page 19 DisplayPort®: 48 ~ 144 Hz Refresh Rates HDMI®: 48 ~ 100 Hz Aspect Ratio 21:9 Viewing Angles (H/V) 178°/178° Backlight Default Color Temperature 6500K Maximum Brightness 400cd/m ² Contrast Ratio 3000:1 Number of Colors > 16.7 million Dot Pitch 0.23175 x 0.23175 mm Response Time 4ms (MPRT 1ms) English, Chinese, Korean, French,...
-
Page 20: Regulatory Compliance
(2) this device must accept any interference received, including interference that may cause undesired operation. Modifying the equipment without Monoprice's authorization may result in the equipment no longer complying with FCC requirements for Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense. - Page 21 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Monoprice™, Dark Matter™, the Dark Matter logo, and all Monoprice logos are trademarks of Monoprice Inc. HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
