APPENDIX C Outline and Installation Drawings
THESE FOUR ITEMS
PROVIDED
PRE-ASSEMBLED
PART OF
330-00053-01
212-00022-00
125-00165-00
330-00053-01
011-00950-03
BAGGED KIT
330-00625-37
115-01879-00
212-00024-04
211-63234-10
QTY 4
233-00087-00
190-01553-00
Revision G
CONNECTOR KIT
011-03240-00
211-63234-08
211-60209-09
212-00018-04
212-20065-00
117-00147-01
GTR200 CONNECTOR KIT
011-03240-00
GTR200 RACK
115-01878-00
GTR200 UNIT
011-02980-00
Figure C-2 GTR 200 Assembly Drawing
GTR 200 Installation Manual
Page C-2
