- Page 1 ELINCHROM LTD, RENENS, SWITZERLAND USER MANUAL GEBRAUCHSANLEITUNG MANUEL D’UTILISATION MANUALE D’USO MANUAL DE INSTRUCCIONES ZOOM Pro HD - 20192 ZOOM Action - 20193 ZOOM Pro - 20191 Elinchrom SA ZOOM Head - Made in Switzerland - 12.07.2011 (73012)
-
Page 2: Table Of Contents
User Manual Table of contents Introduction Declaration of conformity CE / Disposal Characteristics User Safety Information Before You Start Replacing the Plug-In Flash Tube ZOOM Head Accessories Technical Data Maintenance Warranty... -
Page 3: Introduction
This manual may show images of products with accessories, which are not part of Sets or single units. Elinchrom set and single unit configurations may change without advise and may differ in other countries. Please find actual configurations at www.elinchrom.com For further details, upgrades, news and the latest information about the Elinchrom System, please regularly visit the Elinchrom website. -
Page 4: Declaration Of Conformity
E-Mail: elinchrom@elinchrom.ch ELINCHROM S.A. hereby declares that the equipment bearing the trade name and model number specified above was tested conforming to the applicable FCC rules, and that all the necessary steps have been taken and are in force to assure that the production units of the same equipment will continue to comply with the Commissions requirements. -
Page 5: Characteristics
If you have any question on disposal, please contact your local office or your local ELINCHROM Agent (please visit our website for a list of all ELINCHROM agents worldwide). CHARACTERISTICS Three versions; ZOOm PrO HD, ZOOm aCTiOn and ZOOm PrO •... -
Page 6: User Safety Information
The ZOOM PRO HD version offers a high performance plug-in flash tube with heavy-duty electrodes for maximum colour stability and hard use in digital photography. The ZOOM PRO HD is the best choice for catalogue and 3D turntable imaging. Maximum 50... - Page 7 For this reason the flash tube is covered with a glass dome. In case of a damaged flash tube or a broken security cover the flashhead must be immediately unplugged from the power pack and sent to an authorized Elinchrom customer service.
-
Page 8: Before You Start
Elinchrom power packs. Use only original Elinchrom accessories and reflectors. The warranty does not cover damages forced by third party accessories and reflectors. -
Page 9: Replacing The Plug-In Flash Tube
User Manual REpLACING THE pLUG-IN fLASH TUBE Elinchrom uses high quality long-life plug-in flash tubes specifically made for the ZOOM Heads. To exchange a user replaceable plug-in flash tube, please follow the instructions below: Switch the EL- power pack OFF. -
Page 10: Zoom Head Accessories
Check if the Reflector is well fitted. Reconnect the flash cable to the power pack and switch the unit on. ZOOM HEAD ACCESSORIES fLASH TUBES: ZOOM PRO HD // 24082 ZOOM ACTION // 24083 ZOOM PRO // 24081 HALOGEN LAMpS: MAX. -
Page 11: Technical Data
Max. flash power 3000 ws / J load Compatible All Elinchrom power packs since 1981 power packs Multi-voltage All Zoom Heads can be used with 110 V or 230 V EL power packs. Only the Halogen lamp and the fuse must apply to the correct... - Page 12 User Manual REfLECTOR ZOOM TABLE REfLECTOR Ø EL-NO. HOT SpOT wIDE None 80° 81° Reflector 18 cm 60° 26144 60° 74° Reflector 21 cm 50° 26141 52° 63° Reflector 26 cm 43° 26137 42° 53° Hot spot Wide ZOOM fLASHHEADS - MODELLING LAMpS fUSES MOD- LAMp fUSES (SOCKET GX 6.35)
-
Page 13: Maintenance
To achieve maximum protection of the unit when sending it in for service, the original packaging should be kept. Sales / Service / rental For service and sales, please contact your local Elinchrom Distributor. For more information, contact and support, please visit http://www.elinchrom.ch/distrib.php... -
Page 14: Warranty
This ELINCHROM product will be repaired free of charge by the vending agent if during a period of 24 months from date of purchase its working order is impaired through a manufacturing or material defect. The faulty product should be immediately sent to the authorized dealer or ELINCHROM agent. - Page 15 Per favore registrare il suo prodotto Elinchrom in linea sul sito: Por favor registre su producto Elinchrom por internet: www.elinchrom.com / SUPPORT / LOGIN In case you cannot register your Elinchrom unit via internet, please fill in the Guarantee card and post it to ELINCHROM. ✂...
- Page 16 Elinchrom SA ZOOM Head - Made in Switzerland - 12.07.2011 (73012)
