HuddleCamHD 10X 720p Datasheet

Compatibility
• Windows 7 & 8
• Mac OS X
• Adobe Connect
• BlueJeans
• Cisco Jabber
• Cisco WebEx
• Easy Meeting
• Facetime
• Fuzebox
• Google Hangout
• GoToMeeting
• Lifesize
• Microsoft Lync
• Polycom RealPresence
• Radavision
• Spontania
• Skype
• TurboMeeting.US
• Vidyo
• Vsee
• Zoom.US

Specifications

Camera & Lens
Video CMOS Sensor
Frame Rate
Lens Zoom
Field of View
Features
• 10X Optical Zoom
• USB 2.0
• RS-232
• 1920 x 1080
• 50° Field of View
• Up to 30fps
• 64 Presets
• IR Remote
1
2
4
3
Lens
1.
10x Optical Zoom.
2. IR Receiver
To receive IR remote
controller signal.
Power LED
3.
Blue LED blinks when unit is
powered, Orange LED blinks
for Stand-By status.
1/3" CMOS, 2.1 Mega Pixel
30fps 1920 x 1080p
10X Optical Zoom f=5 -50mm F2.0-2.8
50°
The HuddleCamHD 10X 720p is ideal for
a small to medium sized meeting
rooms. This camera is compatible
with every system that accepts
USB cameras.
6
IR Receiver
4.
To receive IR remote
controller signal.
DC IN 12V Socket
5.
Only use the Power Adapter
supplied with this camera.
IR Receiver
6.
To receive IR remote
controller signals.
What's in the Box
10X Zoom USB 2.0 Camera
12V/2.0A DC Power Adapter
Mounts: Tripod Mount (1), Ceiling Mount (1)
USB 2.0 Data Cable (9ft) Serial Control Cable, RS-232C to RS-485 Cable
IR Remote Control
User Manual
1
HuddleCamHD 10X 720p
Conferencing Camera
DATA SHEET
HuddleCamHD
9
8
5
7
VISCA IN Port
7.
For hard wired remote control
from a 3rd party PC, joystick, etc...
VISCA Out Port/RS485
8.
Used for daisy chaining multiple
cameras for RS-232 RS-485 control.
USB 2.0 Interface
9.
For connection to PC (USB 2.0 port.
Will also function in a USB 3.0 port
as USB 2.0 device).
