Specifications
ExpressCard (34mm form factor)
Bus Interface
USB 3.0 rev1.0
Intel xHCI rev0.95
2 x USB 3.0 type A Female
External Connectors
1 x DC power connector
Chipset ID
NEC uPD720200
Maximum Data Transfer Rate
USB 3.0: 5Gbps
Operating Temperature
0°C ~ 50°C (32°F ~ 122°F)
Storage Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Humidity
0% ~ 85% RH
5VDC, 2A, type H plug,
Power Adapter (optional)
center positive
Windows 2000/XP/Server 2003/Vista/
Compatible Operating Systems
7 (32/64-bit) /8 (32/64-bit)
Instruction Manual
4
