7. Replace the tailpiece, hold down the control pin and screw the cap fully on without tightening. Ensure control pin projects to lock
the cap.
Test the key operation
If the key is difficult to insert or tight when turning, then the cap maybe too tight. Loosen the cap one notch at a time and try the
key again. If the key inserts and turns OK, but is difficult to remove, then the cap may be too loose. Tighten the cap one notch at a
time. Adjust the cap until the key inserts, turns and removes easily.
Caution! Do not insert the key in the cylinder once you have removed the screw-cap
PROGRAMMING
* First change the factory Master Code – see program 10. If the Master or Sub-Master Code is entered 3 times
consecutively without performing a programming function, a penalty time of 10 seconds is activated.
Note: The Master Code and Sub-Master Code MUST always start with #.
Codes can only be the same length as the Master Code.
A
or
in the Key Sequence below indicates LED illumination.
If entered, a Sub-Master Code can be used instead of the Master Code for all programs except program 10 and 12.
ENTER NEW USER CODE Program 01
Key Sequence
#Master Code
01
User Code ID (eg 05), New Code (eg 4321)
Result
New Code 4321 entered at User Code ID 05
(•
when user enters code)
SUPEND USER CODE Program 02
Key Sequence
#Master Code
02
User Code ID (EG 05)
Result
User Code at ID 05 suspended
(••
when user 05 enters code)
RESTORE USER CODE Program 03
Key Sequence
#Master Code
03
User Code ID (eg 05)
Result
User Code at ID 05 restored
(•
when user 05 enters code)
SUSPEND ALL USER CODES Program 04
Key Sequence
#Master Code
04
••
Result
All User Codes suspended
(••
when all users enter code)
RESTORE ALL USER CODES Program 05
Key Sequence
#Master Code
05
••
RESULT
All User Code restored
(•
when all users enter code)
CHANGE UNLOCK TIME Program 06
Key Sequence
#Master Code
06
enter open time
(range 2 – 9 secs)
••
RESULT
After code entry the lock will unlock for the set time
(Factory pre-set time is 4 seconds)
••
••
••
