CL300 Mortise Latchset Installation Instructions
Contents
1
2
3
4
5
6
7
8
9
10
11
12
Front plate
Back plate
(hold-open models have a
sliding snib)
Gaskets x 2
Spring loaded spindle
3
3
Latch 2 / " (60mm) and 2 / "
8
4
(70mm) backset
Strike plate
Wood screws x 6
Use with latch & strike plate
Tweezers (for changing the
code)
Fixing bolts 3 supplied (spare
x1)
Code tumblers (spare x 2)
Code card
2 keys - key override models
only
Page 1
Find more online at www.codelockssupport.com
Tools Required for installation:
• Power drill
1" (25mm), 21/8" (54mm) & 5/16" (8mm) drill bits
• Bradawl
• Phillips screwdriver size 2
• Chisel maximum 1" (25mm)
• Hammer/Mallet
• Tape measure
• Stanley knife
• Pencil
• Adhesive Tape
